5-188027-3 Product Details
Live Product Chat
Product View
Standard Board Mount Connectors
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5-188027-3
T E I nternal N umber: 5 - 1 8 8 0 2 7 - 3
Product Highlights:
l
Number of Positions = 25
l
Receptacle
l
PC B Mount Angle = Right Angle
l
Product Series = HDP-20
l
With Mating C onnector Lock
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Number of Positions
= 25
l
Gender
= Receptacle
l
PC B Mount Angle
= Right Angle
l
Product Series
= HDP-20
l
Mating C onnector Lock
= With
l
Mating C onnector Lock Type = Bushing with Through Hole
l
PC B Retention Feature
= No
l
Shell Type
= Full Metal
l
Shell Size
= 3
l
Footprint (mm [in])
= 9.50 [.374]
l
PC B Thickness (in [mm])
= 0.063 [1.60]
l
Grounding Indents
= Without
l
Grounding Straps
= Without
l
PC B Mount Style
= Through Hole
l
C olor C ode
= None
l
Sealed = No
l
C olor = Black
l
Shell Material = Steel
Mechanical Attachment:
l
Panel Attachment
= Without
Termination Related Features:
l
Grounding C lips
= Without
l
Termination Post Length (mm [in])
= 3.20 [0.126]
l
Solder Tail C ontact Plating
= Bright Tin-Lead
Body Related Features:
l
Shell Plating = Tin
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (30)
l
C ontact Base Material = Phosphor Bronze
l
Approved Standards = DIN 41652
l
Performance Level = Level 3
Housing Related Features:
l
Housing Material = Polyester GF
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Operation/Application:
l
Application = Standard
Other:
l
Brand = AMP
