5-188028-1

Description
CONNECTOR, 37 CONTACT(S), FEMALE, D SUBMINIATURE CONNECTOR, SOLDER, RECEPTACLE
CategoryThe connector    The connector
File Size116KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

5-188028-1 Overview

CONNECTOR, 37 CONTACT(S), FEMALE, D SUBMINIATURE CONNECTOR, SOLDER, RECEPTACLE

5-188028-1 Parametric

Parameter NameAttribute value
MakerTE Connectivity
Reach Compliance Codeunknown
Other featuresSTANDARD: DIN 41652
Body/casing typeRECEPTACLE
Connector typeD SUBMINIATURE CONNECTOR
Contact to complete cooperationGOLD (50)
Contact completed and terminatedTIN LEAD
Contact point genderFEMALE
DIN complianceYES
empty shellNO
Filter functionNO
IEC complianceNO
insulator materialGLASS FILLED POLYESTER
JESD-609 codee0
MIL complianceNO
Manufacturer's serial number188028
Mixed contactsNO
Installation typeBOARD
OptionsGENERAL PURPOSE
Shell surfaceTIN
Shell materialSTEEL
Housing size4/C
Termination typeSOLDER
Total number of contacts37
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
D-Subminiature C onnectors
>
Product Feature Selector
> Product Details
5-188028-1 Product Details
Live Product Chat
Product View
Standard Board Mount Connectors
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5-188028-1
T E I nternal N umber: 5 - 1 8 8 0 2 8 - 1
Product Highlights:
l
Number of Positions = 37
l
Receptacle
l
PC B Mount Angle = Right Angle
l
Product Series = HDP-20
l
With Mating C onnector Lock
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Number of Positions
= 37
l
Gender
= Receptacle
l
PC B Mount Angle
= Right Angle
l
Product Series
= HDP-20
l
Mating C onnector Lock
= With
l
Mating C onnector Lock Type = Bushing with Through Hole
l
PC B Retention Feature
= No
l
Shell Type
= Full Metal
l
Shell Size
= 4
l
Footprint (mm [in])
= 9.50 [.374]
l
PC B Thickness (in [mm])
= 0.063 [1.60]
l
Grounding Indents
= Without
l
Grounding Straps
= Without
l
PC B Mount Style
= Through Hole
l
C olor C ode
= None
l
Sealed = No
l
C olor = Black
l
Shell Material = Steel
Mechanical Attachment:
l
Panel Attachment
= Without
Termination Related Features:
l
Grounding C lips
= Without
l
Termination Post Length (mm [in])
= 3.20 [0.126]
l
Solder Tail C ontact Plating
= Bright Tin-Lead
Body Related Features:
l
Shell Plating = Tin
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (50)
l
C ontact Base Material = Phosphor Bronze
l
Approved Standards = DIN 41652
l
Performance Level = Level 1
Housing Related Features:
l
Housing Material = Polyester GF
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Operation/Application:
l
Application = Standard
Other:
l
Brand = AMP
