Frontier Electronics Corp.
667 E. COCHRAN STREET, SIMI VALLEY, CA 93065
TEL: (805) 522-9998 FAX: (805) 522-9989
E-mail: frontiersales@frontierusa.com
Web: frontierusa.com
Common Mode Line Filters—
CFU1001 series
A. Specifications:
Part
Number
Inductance
(mH)
/ L1-L2/
(uH) Max.
50
100
100
100
200
200
200
200
400
DCR
(OHMS) Max.
0.10
0.18
0.30
0.50
1.00
2.80
3.50
6.30
8.00
Rated Current
(A) rms.
2.00
1.70
1.20
1.00
0.50
0.30
0.25
0.20
0.10
2 x 0.20
CFU1001 -01
2 x 0.47
CFU1001 -02
2 x 0.70
CFU1001 -03
2 x 1.00
CFU1001 -04
2 x 2.00
CFU1001 -05
2 x 5.60
CFU1001 -06
2 x 10.0
CFU1001 -07
2 x 22.0
CFU1001 -08
2 x 40.0
CFU1001 -09
Note:
: “H” for
Horizontal
mounting type.
“V” for
Vertical
mounting type.
B.
Mechanical Dimensions:
C. General information:
1.
2.
3.
4.
5.
6.
7.
Test Condition: 1.0KHz / 1V.
Electrical specifications at 25ºC.
Temperature Rise:
≤40ºC.
Operating temperature: -20ºC TO +105ºC.
Insulation Resistance: 100M OHMS at 500VDC.
Rated Voltage: 100V to 270V / 50-60 Hz.
Hi-Pot Voltage: 1500VAC for one minute.
Custom specifications are available.
Note:
RoHS
compliant; for the
ROHS
parts, we add “-LFR” at the end of the P/N.
Common Mode Line Filter P/N: CF1001 Series
Rev. A
Jan. 01, 2006 Page 1 of 1
