SPECIFICATION CONTROL DRAWING
Product Revisions
Product
Name
B-155-3801
B-155-3802
B-155-3803
B-155-3805
B-155-3806
B-155-3807
B-155-3809
B-155-3810
B-155-3811
B-155-3813
A
B
A
A
A
A
A
A
A
A
Product Dimensions
L
øA
max
min
1.7 [0.065]
26.0 [1.025)
1.95 [0.075]
2.7 [0.105]
4.5 [0.180]
6.0 [0.235]
7.0 [0.275]
42.0 [1.655]
8.7 [0.340]
9.7 [0.382]
10.7 [0.420]
13.0 [0.510]
B
max
1.7 [[0.065]
1.95 [0.075]
2.7 [0.105]
4.5 [0.180]
6.0 [0.235]
7.0 [0.275]
8.7 [0.340]
9.7 [0.382]
10.7 [0.420]
13.0 [0.510]
Cable Dimensions
øC
min
0.9 [0.035]
1.1 [0.045]
1.8 [0.070]
2.3 [0.090]
3.3 [0.130]
3.7 [0.145]
4.2 [0.165]
6.8 [0.268]
7.1 [0.280]
8.9 [0.350]
øD
min
0.4 [0.015]
0.6 [0.025]
1.3 [0.050]
1.8 [0.070]
2.8 [0.110]
3.2 [0.125]
3.7 [0.145]
6.0 [0.236]
6.6 [0.260]
8.4 [0.330]
Qty:
Item 2
1
1
1
1
1
1
2
2
2
1
MATERIAL
1. INSULATION SLEEVE: Heat-shrinkable, transparent clear, radiation cross-linked modified polyolefin.
2. SOLDER PREFORM WITH FLUX: Qty: see table (one solder washer shown).
SOLDER:
TYPE Sn42Bi58 per ANSI / J-STD-006.
FLUX:
TYPE ROM1 per ANSI / J-STD-004.
3. MELTABLE RING: Thermally stabilized thermoplastic. Color: clear.
4. MELTABLE RING: Thermally stabilized thermoplastic. Color: blue.
APPLICATION
1. These controlled soldering devices are designed for termination of a bare or tin-plated copper shield on a cable, having an
Insulation rated for at least +85C minimum.
2. Temperature range: -55C to +125C.
3. When installed properly, it will meet the performance requirements of TE Connectivity / Raychem Specification RT-1404.
4. For installation procedure and application equipment consult RPIP-824-00 or H54286.
For best results, prepare
the cable as shown:
TE Connectivity
300 Constitution Drive,
Menlo Park, CA. 94025, U.S.A.
Unless otherwise specified dimensions are in millimeters.
[Inches dimensions are shown in brackets]
TOLERANCES:
0.00 N/A
0.0 N/A
0 N/A
PREPARED BY:
ANGLES: N/A
TITLE:
Raychem
SOLDERSLEEVE ONE STEP SHIELD
TERMINATOR, LEAD-FREE
DOCUMENT NO.:
B-155-38XX
Rev:
DATE:
TE Connectivity reserves the right to amend
this drawing at any time. Users should evaluate
ROUGHNESS IN
the suitability of the product for their
MICRON
application.
DCR NUMBER:
REPLACES:
B1
CAGE CODE :
SCALE:
16-Apr-11
SIZE:
SHEET:
L RODRIGUEZ
D060320
D050171
06090
---
A
1 of 1
Print Date: 9-May-11
© 2005, 2011 Tyco Electronics Corporation, a TE Connectivity Ltd. Company. All Rights Reserved.
If this document is printed it becomes uncontrolled. Check for the latest revision.
