Produktdatenblatt | Version 1.1
LO L296
www.osram-os.com
LO L296
SMARTLED
®
0603
The innovative SMARTLED 0603 joins the success-
ful family of TOPLED. Invested with the same high
quality, its unique features are due to set new stan-
dards in product development and design, opening
up new applications on a new scale.
Applications
—
Electronic Equipment
—
White Goods
Features:
—
Package: SMT package 0603, colorless diffused resin
—
Chip technology: InGaAlP
—
Typ. Radiation: 150°
—
Color:
λ
dom
= 606 nm (● orange)
—
Corrosion Robustness Class: 3B
—
ESD: 2 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 2)
Discontinued
1
Version 1.2
| 2019-07-16
LO L296
Characteristics
I
F
= 20 mA; T
A
= 25 °C
Parameter
Peak Wavelength
Dominant Wavelength
3)
I
F
= 20 mA
Viewing angle at 50% I
V
Forward Voltage
4)
I
F
= 20 mA
Reverse current
2)
V
R
= 5 V
Temperature Coefficient of Peak Wavelength
-10°C ≤ T ≤ 100°C
Temperature Coefficient of Forward Voltage
-10°C ≤ T ≤ 100°C
Real thermal resistance junction/ambient
5)6)
Real thermal resistance junction/solderpoint
5)
Symbol
λ
peak
λ
dom
typ.
min.
typ.
max.
typ.
min.
typ.
max.
typ.
max.
typ.
typ.
max.
max.
Values
610 nm
600 nm
606 nm
609 nm
160 °
1.85 V
2.00 V
2.35 V
0.01 µA
10 µA
0.13 nm / K
-1.7 mV / K
500 K / W
290 K / W
2φ
V
F
I
R
TC
λpeak
TC
VF
R
thJA real
R
thJS real
Discontinued
4
Version 1.2
| 2019-07-16
