F71858
F71858
Hardware KBC with ACPI, Temp. and Fan Control
Release Date: June, 2009
Version: V0.29P
June, 2009
V0.29P
F71858
F71858 Datasheet Revision History
Version
0.1P
0.11P
0.12P
0.13P
0.14P
0.15P
0.16P
0.17P
0.18P
Date
2005/08/12
2005/09/05
2005/09/12
2005/11/02
2005/11/20
2005/11/30
2006/01/05
2006/01/13
2006/02/15
Page
-
5
-
-
-
-
-
-
-
-
Revision History
Preliminary Version
Updated Hardware Monitor Functions of Feature List
Updated Pin Type Description.
Added Application Circuit.
Added Function/Register Description
Register Modify
Register Modify
Register modify and pin17/pin10 modify
Updated application circuit and register description for LAA
version chip.
Modified typo.
Modified Fan1~Fan3 Duty Change Rate Select Register
(CR9Bh)
Removed HW Monitor Register Index 70h (HW_IRQ
Enable Register)
Added Electrical Characteristics Description.
Updated Register description.
Added Fan4 D0h-D1h registers description.
Modified ACPI Control Register Index F5h bit 7
Modified Select KB/MO Wakeup Register 27h bit 7
Modified name of VT1/VT2/VT3 which
T1/T2/T0. T0 means local temperature.
change
to
0.19P
2006/03/15
-
-
-
0.20P
0.21P
2006/04/13
2006/05/03
55
35
32
0.22P
0.23P
2006/06/15
2006/09/06
-
-
-
This version datasheet is for LAC version chip use.
Added Fan control machine by internal clock when system
boot up.
Modified typo.
0.24P
0.25P
2006/11/10
2006/12/19
-
-
-
This version datasheet is for LAD version chip use.
Modified typo.
Updated Application Circuit.
Company readdress
Rename ALERT Pin to HW_IRQ
Made Correction & Clarification
0.26P
0.27P
2007/7/6
2009/1/21
-
-
0.28P
0.29P
2009/4/1
2009/6/15
Made Correction & Clarification
Modified Application Circuit.
Made Correction & Clarification
June, 2009
V0.29P
F71858
Please note that all data and specifications are subject to change without notice. All the trade marks of products
and companies mentioned in this data sheet belong to their respective owners.
LIFE SUPPORT APPLICATIONS
These products are not designed for use in life support appliances, devices, or systems where malfunction of these
products can reasonably be expected to result in personal injury. Customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify Fintek for any damages resulting from
such improper use or sales.
June, 2009
V0.29P
F71858
Table of Content
1.
2.
3.
4.
5.
General Description ........................................................................................................5
Feature List..................................................................................................................... 5
Key Specification ............................................................................................................ 6
Pin Configuration ............................................................................................................ 7
Pin Description ............................................................................................................... 8
5.1 Power Pin.................................................................................................................... 8
5.2 LPC Interface ..............................................................................................................8
5.3 Keyboard Controller ....................................................................................................9
5.4 ACPI............................................................................................................................ 9
5.5 H/W Monitor ................................................................................................................9
Function Description ..................................................................................................... 11
6.1 Keyboard Controller .................................................................................................. 11
6.2 ACPI function ............................................................................................................ 13
6.3 Hardware monitor......................................................................................................17
6.4 LED function ............................................................................................................. 27
6.5 AMDSI and Intel SST PECI Function ........................................................................ 28
7.
Register Description ..................................................................................................... 29
7.1 Global Control Registers ........................................................................................... 29
7.2 KBC Registers........................................................................................................... 30
7.3 ACPI and PME Registers.......................................................................................... 31
7.4 Hardware Monitor Registers (Index port: 0x295; Data port: 0x296) .......................... 35
8.
PCB Layout Guide ........................................................................................................ 54
9.
Electrical Characteristics .............................................................................................. 56
9.1 Absolute Maximum Ratings ...................................................................................... 56
9.2 DC Characteristics .................................................................................................... 56
9.3 DC Characteristics Continued ................................................................................... 56
9.4 AC Characteristics .................................................................................................... 57
10. Ordering Information..................................................................................................... 61
11. Package Dimensions (48LQFP) ................................................................................... 61
12. Application Circuit ......................................................................................................... 62
6.
June, 2009
V0.29P
F71858
1. General Description
The F71858 is hardware KBC integrating the ACPI, temperature sensing and fan control
functions specific for the legacy free MB application.
systems.
The KBC functions include one keyboard and
one PS/2 mouse, and can be used with IBM
®-
compatible personal computers or PS/2-based
The controller receives serial data from the keyboard or PS/2 mouse, checks the parity of
the data, and presents the data to the system as a byte of data in its output buffer. The controller will
assert an interrupt to the system when data are placed in its output buffer.
The F71858 provides the ACPI control signals as well such as S3 state, resume reset, PCI reset
outputs or power OK signals.
The power LED is programmable and compliant with PC2001.
One HW_IRQ (alert signal) will be
4 fan monitoring inputs and 3 fan
As to the environment sensing functions, F71858 provides 2 remote analog dual current temp.
sensing inputs and one internal local temperature sensing.
issued while the temperature is over the programmable limit.
controlling outputs provide Fintek’s patented auto-fan controlling features. Besides, the F71858
supports AMDSI and Intel PECI/SST interfaces for next generation CPU temp. sensing technology.
F71858 is in LPC interface and powered by 3VCC, 3V standby, and battery.
48 pin LQFP Green Package.
The package is in
2. Feature List
General Functions
Comply with LPC Spec. 1.1
Hardware Keyboard Controller support one PS/2 keyboard and one PS/2 mouse
Hardware Gate A20 and Hardware Keyboard Reset
Support DPM (Device Power Management), ACPI
KBC
LPC interface support serial interrupt channel 1, 12.
Two 16bit Programmable Address fully decoder, default 0x60 and 0x64.
Support two PS/2 interface, one for PS/2 mouse and the other for keyboard.
Keyboard’s scan code support set1, set2.
Programmable compatibility with the 8042.
Support both interrupt and polling modes.
Hardware Gate A20 and Hardware Keyboard Reset.
5
June, 2009
V0.29P
