Microwave Components
To apply for wide range of mobile communication and optical
communication.
30 years of tantalum film development history is combined
with microwave technology.
Features
1. High environmental stability and high reliability
2. Non-cut resistance trimming for high frequency
characteristic and stability
3. A variety of custom designs are available.
Applications
Mobil phone base circuit terminator
Characteristic impedance compensation
Terminations
Plate Types
Style (I)
B
3
C
A
DL-05
Impedance
( )
50,100
50,100
50,100
50,100
50
50
DL-20
DL-30
Frequency
(GHz)
3
6
4
3
4
4
Power Rating
(W)
5.0
15
25
50
75
150
DL-50
DL-75
Dimensions(mm)
Type
DL-05
DL-20
B
3
C
A
SWR
1.35
1.20
1.35
1.35
1.35
1.35
Style
(I)
(II)
(II)
(II)
(II)
(II)
A
9.7
13
15
15
21
B
4.1
4.0
4.1
7.0
11.6
C
5
8
10
10
15
H
1.7
1.4
1.7
2.1
2.4
Style (II)
DL-30
DL-50
DL-75
DL-150
1 Pat. Pending
2 Under development H:Lead height
Applications; For termination of high frequency circuit.
Distributor/Synthesyzer of oscillator circuit.
Coaxial Type Resistor
Type
For SMA
Rated wattage
(W)
1/8 (1/2)
Impedance
( )
50,75
Tolerance
(%)
2, 1
Custom supplied contact acceptable.
Application; Built in resistor for coaxial type terminator.
Coaxial Types
hexagon 8.0
8.5
12.0
5.0
HTR-601A
Type
HTR-601A
HTR-701
1.7
HTR-701
SWR
1.20
1.35
Frequency
(GHz)
18
18
Power Rating
(W)
0.25
1.0
Features
SMA type
Direct connection type strip line
Impedance
( )
50
50
6.0
8.0
1.55
0.55 depth 1.6
1.27
Applications; For termination of high frequency circuit.
Specifications are subject to change without notice.
Specifications are subject to change without notice.
