EVERLIGHT ELECTRONICS CO., LTD.
Technical Data Sheet
3mm Power LED
Preliminary
30-01-B84-RFC-D4T1U1DH-AM
Lead (Pb) Free Product - RoHS Compliant
Feature
‧
‧
‧
‧
‧
‧
Piranha package.
Colorless clear resin.
Low thermal resistance
Packaged in tubes for automatic insertion equipment.
Total flux: 7150to 14250 mlm at 70mA.
Qualification according to AEC-Q101.
This is a preliminary specification
intended for design purposes and
subject to change without prior
notice.
Applications
‧
Automotive Lighting
‧
Electronic signs and signals
‧
General lighting application
Device Selection Guide
Chip
Material
AlGaInP
Emitted Color
Red
Resin Color
Water Clear
Everlight Electronics Co., Ltd.
Device No.:
Preliminary
http://www.everlight.com
Published date: Aug-6-2009
Rev.:
1.0
Vicky Feng
Page:
1 of 13
Created by:
EVERLIGHT ELECTRONICS CO., LTD.
Technical Data Sheet
3mm Power LED
Preliminary
30-01-B84-RFC-D4T1U1DH-AM
Absolute Maximum Ratings (Ta=25
℃
)
Parameter
Reverse Voltage
Forward Current
Peak Forward Current
(Duty 1/10 @1KHz)
Power Dissipation
Junction Temperature
Operating Temperature
Storage Temperature
Thermal Resistance
Symbol
V
R
I
F
I
FP
Pd
T
j
T
opr
Tstg
Rth
J-A
ESD
HBM
ESD
MM
T
sol
Rating
12
70
150
210
120
-40 ~ +100
-40 ~ +110
150
2000
200
Unit
V
mA
mA
mW
℃
℃
℃
K/W
V
V
ESD
(Classification acc. AEC Q101)
Soldering Temperature
Wave Soldering : 260
℃
for 5 sec.
Hand Soldering : 350
℃
for 3 sec.
Everlight Electronics Co., Ltd.
Device No.:
Preliminary
http://www.everlight.com
Published date: Aug-6-2009
Rev.:
1.0
Vicky Feng
Page:
2 of 13
Created by:
EVERLIGHT ELECTRONICS CO., LTD.
Technical Data Sheet
3mm Power LED
Preliminary
30-01-B84-RFC-D4T1U1DH-AM
Electro-Optical Characteristics (Ta=25
℃
)
Parameter
Total Flux
Viewing Angle
Peak Wavelength
Dominant Wavelength
Spectrum Radiation Bandwidth
Forward Voltage
Reverse Current
Symbol
Φv
2θ
1/2
λ
p
λ
d
∆λ
V
F
I
R
Min.
7150
---
---
620
---
1.9
---
Typ.
---
85
631
---
20
---
---
Max.
14250
---
---
632
---
2.9
10
Unit
mlm
deg
nm
nm
nm
V
µA
Condition
I
F
=70mA
I
F
=70mA
I
F
=70mA
I
F
=70mA
I
F
=70mA
I
F
=70mA
V
R
=5V
Note:
1. Tolerance of Total Flux: ±11%
2. Tolerance of Dominant Wavelength: ±1nm
3. Tolerance of Forward Voltage: ±0.1V
Everlight Electronics Co., Ltd.
Device No.:
Preliminary
http://www.everlight.com
Published date: Aug-6-2009
Rev.:
1.0
Vicky Feng
Page:
3 of 13
Created by:
EVERLIGHT ELECTRONICS CO., LTD.
Technical Data Sheet
3mm Power LED
Preliminary
30-01-B84-RFC-D4T1U1DH-AM
Bin Range of Forward Voltage (Ta=25
℃
)
Bin Code
1
2
3
4
5
Min.
1.9
2.1
2.3
2.5
2.7
Max.
2.1
2.3
2.5
2.7
2.9
Unit
Condition
V
I
F
=70mA
Everlight Electronics Co., Ltd.
Device No.:
Preliminary
http://www.everlight.com
Published date: Aug-6-2009
Rev.:
1.0
Vicky Feng
Page:
4 of 13
Created by:
EVERLIGHT ELECTRONICS CO., LTD.
Technical Data Sheet
3mm Power LED
Preliminary
30-01-B84-RFC-D4T1U1DH-AM
Bin Range of Dominant Wavelength (Ta=25
℃
)
Bin Code
2
3
4
Min.
620
624
628
Max.
624
628
632
nm
I
F
=70mA
Unit
Condition
Note:
Tolerance of Dominant Wavelength: ±1nm
Bin Range of Total Flux (Ta=25
℃
)
Bin Code
T1
T2
U1
Note:
Tolerance of Total Flux: ±11%
Min.
7150
9000
11250
Max.
9000
11250
14250
mlm
I
F
=70mA
Unit
Condition
Everlight Electronics Co., Ltd.
Device No.:
Preliminary
http://www.everlight.com
Published date: Aug-6-2009
Rev.:
1.0
Vicky Feng
Page:
5 of 13
Created by:
