UNISONIC TECHNOLOGIES CO., LTD
DTC115T
NPN DIGITAL TRANSISTOR
(BUILT- IN BIAS RESISTORS)
FEATURES
* Built-in bias resistors that implies easy ON/OFF applications.
* The bias resistors are thin-film resistors with complete isolation to
allow negative input.
NPN SILICON TRANSISTOR
EQUIVALENT CIRCUIT
ORDERING INFORMATION
Order Number
Lead Free
Halogen Free
DTC115TL-AE3-6-R
DTC115TL-AE3-6-R
Note: Pin Assignment: E: Emitter, B: Base, C: Collector
Package
SOT-23
Pin Assignment
1
2
3
E
B
C
Packing
Tape Reel
MARKING
www.unisonic.com.tw
Copyright © 2011 Unisonic Technologies Co., Ltd
1 of 2
QW-R206-063,Ba
DTC115T
ABSOLUTE MAXIMUM RATINGS
(T
A
=25°C)
NPN SILICON TRANSISTOR
PARAMETER
SYMBOL
RATINGS
Collector-base voltage
V
CBO
50
Collector-emitter voltage
V
CEO
50
Emitter-base voltage
V
EBO
5
Collector current
I
C
100
Collector Power dissipation
P
C
200
Junction temperature
T
J
150
Storage temperature
T
STG
-55 ~ +150
Note Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
UNIT
V
V
V
mA
mW
°C
°C
ELECTRICAL SPECIFICATIONS
(T
A
=25°C, unless others specified)
PARAMETER
SYMBOL
Collector-Base Breakdown Voltage
BV
CBO
Collector-Emitter Breakdown Voltage
BV
CEO
Emitter-Base Breakdown Voltage
BV
EBO
Collector Cutoff Current
I
CBO
Emitter Cutoff Current
I
EBO
Collector-Emitter Saturation Voltage
V
CE(SAT)
DC Current transfer Ratio
h
FE
Input Resistance
R1
Transition Frequency
f
T
Note: Transition frequency of the device
TEST CONDITIONS
I
C
=50μA
I
C
=1mA
I
E
=50μA
V
CB
=50V
V
EB
=4V
I
C
=1mA, I
B
=0.1mA
V
CE
=5V, I
C
=1mA
V
CE
=10V, I
E
=-5mA, f=100MHz
MIN
50
50
5
TYP
MAX
UNIT
V
V
V
μA
μA
V
KΩ
MH
Z
100
70
250
100
250
0.5
0.5
0.3
600
130
UTC assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or
other parameters) listed in products specifications of any and all UTC products described or contained
herein. UTC products are not designed for use in life support appliances, devices or systems where
malfunction of these products can be reasonably expected to result in personal injury. Reproduction in
whole or in part is prohibited without the prior written consent of the copyright owner. The information
presented in this document does not form part of any quotation or contract, is believed to be accurate
and reliable and may be changed without notice.
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 2
QW-R206-063,Ba
