DTC143T_11 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> DTC143T_11

DTC143T_11: Description100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92; Categorysemiconductor Discrete semiconductor; File Size144KB，3 Pages; ManufacturerUNISONIC TECHNOLOGIES CO.,LTD; Websitehttp://www.unisonic.com.tw/

Download Datasheet Parametric Compare View All

DTC143T_11 Overview

100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92

DTC143T_11 Parametric

Parameter Name	Attribute value
Maximum collector current	0.1000 A
Maximum Collector-Emitter Voltage	50 V
Number of terminals	3
Processing package description	LEAD FREE PACKAGE-3
state	Active
structure	SINGLE WITH BUILT-IN RESISTOR
Minimum DC amplification factor	20
jedec_95_code	TO-92
jesd_30_code	O-PBCY-W3
Number of components	1
Packaging Materials	PLASTIC/EPOXY
packaging shape	ROUND
Package Size	CYLINDRICAL
larity_channel_type	NPN
wer_dissipation_max__abs_	0.6250 W
sub_category	BIP General Purpose Small Signal
surface mount	NO
Terminal form	WIRE
Terminal location	BOTTOM
transistor applications	SWITCHING
Transistor component materials	SILICON
Rated crossover frequency	250 MHz
dditional_feature	BUILT-IN BIAS RESISTOR RATIO IS 1

Preview

Download Datasheet

View All

UNISONIC TECHNOLOGIES CO., LTD

DTC143E

NPN DIGITAL TRANSISTOR

(BUILT-IN RESISTORS)

FEATURES

* Built-in bias resistors that implies easy ON/OFF applications.

* The bias resistors are thin-film resistors with complete isolation to

allow negative input.

NPN SILICON TRANSISTOR

EQUIVALENT CIRCUIT

ORDERING INFORMATION

Ordering Number

Lead Free

Halogen Free

DTC143EL-AE3-R

DTC143EG-AE3-R

DTC143EL-AL3-R

DTC143EG-AL3-R

DTC143EL-T92-B

DTC143EG-T92-B

DTC143EL-T92-K

DTC143EG-T92-K

DTC143EL-T92-R

DTC143EG-T92-R

Package

SOT-23

SOT-323

TO-92

Pin Assignment

Packing

Tape Reel

Tape Box

Bulk

Tape Reel

MARKING(FOR SOT-23/SOT-323 PACKAGE)

CE3E

E: Lead Free

E: Halogen Free

www.unisonic.com.tw

1 of 3

QW-R206-053,F

DTC143T_11 Related Products

	DTC143T_11	DTC143EG-AE3-R	DTC143EG-AL3-R	DTC143EG-T92-B	DTC143EG-T92-K	DTC143EG-T92-R	DTC143EL-AE3-R	DTC143EL-T92-B	DTC143EL-T92-K	DTC143EL-T92-R
Description	100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92	100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92	100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92	100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92	100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92	100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92	100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92	100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92	100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92	100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92
Number of components	1	1	1	1	1	1	1	1	1	1
surface mount	NO	YES	YES	NO	NO	NO	YES	NO	NO	NO
Transistor component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Number of terminals	3	3	3	3	3	3	3	3	3	-
Terminal form	WIRE	GULL WING	GULL WING	WIRE	WIRE	WIRE	GULL WING	WIRE	WIRE	-
Terminal location	BOTTOM	DUAL	DUAL	BOTTOM	BOTTOM	BOTTOM	DUAL	BOTTOM	BOTTOM	-
transistor applications	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	-
Is it Rohs certified?	-	conform to	conform to	conform to	conform to	-	conform to	conform to	conform to	conform to
package instruction	-	SMALL OUTLINE, R-PDSO-G3	SMALL OUTLINE, R-PDSO-G3	CYLINDRICAL, O-PBCY-W3	CYLINDRICAL, O-PBCY-W3	-	SMALL OUTLINE, R-PDSO-G3	CYLINDRICAL, O-PBCY-W3	CYLINDRICAL, O-PBCY-W3	-
Contacts	-	3	3	3	3	-	3	3	3	-
Reach Compliance Code	-	compli	compli	compli	compli	-	compli	compli	compli	compli
ECCN code	-	EAR99	EAR99	EAR99	EAR99	-	EAR99	EAR99	EAR99	-
Other features	-	BUILT-IN BIAS RESISTOR RATIO IS 1	BUILT-IN BIAS RESISTOR RATIO IS 1	BUILT-IN BIAS RESISTOR RATIO IS 1	BUILT-IN BIAS RESISTOR RATIO IS 1	-	BUILT-IN BIAS RESISTOR RATIO IS 1	BUILT-IN BIAS RESISTOR RATIO IS 1	BUILT-IN BIAS RESISTOR RATIO IS 1	-
Maximum collector current (IC)	-	0.1 A	0.1 A	0.1 A	0.1 A	-	0.1 A	0.1 A	0.1 A	0.1 A
Collector-emitter maximum voltage	-	50 V	50 V	50 V	50 V	-	50 V	50 V	50 V	-
Configuration	-	SINGLE WITH BUILT-IN RESISTOR	SINGLE WITH BUILT-IN RESISTOR	SINGLE WITH BUILT-IN RESISTOR	SINGLE WITH BUILT-IN RESISTOR	-	SINGLE WITH BUILT-IN RESISTOR	SINGLE WITH BUILT-IN RESISTOR	SINGLE WITH BUILT-IN RESISTOR	-
Minimum DC current gain (hFE)	-	20	20	20	20	-	20	20	20	20
JESD-30 code	-	R-PDSO-G3	R-PDSO-G3	O-PBCY-W3	O-PBCY-W3	-	R-PDSO-G3	O-PBCY-W3	O-PBCY-W3	-
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	-
Package shape	-	RECTANGULAR	RECTANGULAR	ROUND	ROUND	-	RECTANGULAR	ROUND	ROUND	-
Package form	-	SMALL OUTLINE	SMALL OUTLINE	CYLINDRICAL	CYLINDRICAL	-	SMALL OUTLINE	CYLINDRICAL	CYLINDRICAL	-
Peak Reflow Temperature (Celsius)	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-
Polarity/channel type	-	NPN	NPN	NPN	NPN	-	NPN	NPN	NPN	NPN
Maximum power dissipation(Abs)	-	0.4 W	0.4 W	0.625 W	0.625 W	-	0.4 W	0.625 W	0.625 W	0.625 W
Maximum time at peak reflow temperature	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-
Nominal transition frequency (fT)	-	250 MHz	250 MHz	250 MHz	250 MHz	-	250 MHz	250 MHz	250 MHz	-
