DC Power Supply Plugs / Jacks
3
P Rectangular Power Supply Jack
● Jack
:
LGP2603-0101F
6
2.6
6.4
1.2
DC Power Supply Plugs / Jacks
3.2
4.8
5.7
2.2
ø0.7
4.6
6.25
■
Features
1. Low profile of 2.6mm height when mounted.
2. 3 pins rectangular power supply jack of the
industry's smallest class.
3. Through-hole reflow soldering ready jack.
4. High resistance for insertion designed our
original structure.
0.4
■
Specification
1. Rating : 2A, 6.3V DC
2. Contact Resistance : 30mΩ max.
3. Insulation Resistance : 100MΩ min. 500V DC
4. Withstanding Voltage : 500V AC (for one minute)
5. Insertion Force : 30N max.
6. Withdrawal Force : 2 to 30N.
7. Operating Temperature Range : –25°C to +70°C
2
■ P.C. Board Dimension
(Top View)
5.7
4x1.1
4x0.6 Through hole(4 place)
(Recommended land
width : 0.5)
4.05
6.25
3.5(Pitch)x2=7
■
Materials and Plating
<Plug>
●
Housing : Thermoplastic Resin, Black, 94V-0
●
Contact : Cu Alloy, Selective Au plating
<Socket>
●
Housing : Thermoplastic Resin, Black, 94V-0
●
Terminal : Cu Alloy, Selective Au Plating
2xø0
.
8
3.2
1.65
2.2
1.3
3x0.7
2
4.8
[t=0.8]
(Land)
Metal mask t=0.15~0.2
Metal mask hole area : land area x 100%
● Plug
:
LLT6004-0001F
1.6
2.1
1
3-0.55
1.95
5.3
2
14.5
10.7
0.8
38
2.8
