Low Pass Filter
50Ω
Operating Temperature
Storage Temperature
RF Power Input*
Max. DC Voltage at pins 1 & 3
DC Current Input to Output
Ceramic
LFCN-7200D+
CASE STYLE: FV1206
PRICE: $2.49 ea. QTY (20)
DC to 7200 MHz
-55°C to 100°C
-55°C to 100°C
8W max. at 25°C
25 VDC
0.5A max. at 25°C
Maximum Ratings
* Passband rating, derate linearly to 3W at 100°C ambient.
Permanent damage may occur if any of these limits are exceeded.
•
excellent power handling, 8W
•
small size
•
7 sections
•
temperature stable
•
hermetically sealed
•
LTCC construction
•
protected by U.S. Patent 6,943,646
Features
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
and Reel
Available Tape cost
no extra
at
Devices/Reel
20, 50, 100, 200, 500,1000, 3000
Pin Connections
RF IN
RF OUT
GROUND
1
3
2,4
Applications
7”
•
harmonic rejection
•
VHF/UHF transmitters/receivers
•
lab use
Electrical Specifications
1,2
at 25°C
Reel Size
Parameter
Pass Band
Insertion Loss
Freq. Cut-Off
VSWR
Rejection Loss
VSWR
F#
DC-F1
F2
DC-F1
F3
F4-F5
F5-F6
F3-F6
Frequency (MHz)
DC-7200
8150
DC-7200
9500
8850-9600
9600-12300
9500-12300
Min.
—
—
—
20
—
—
—
Typ.
—
3.0
1.3
—
30
20
17
Max.
2
—
—
—
—
—
—
Unit
dB
dB
:1
dB
dB
dB
:1
Outline Drawing
(ON TOP)
Stop Band
(ON TOP)
1. DC Resistance to ground is 100 Mohms min.
2. Measured on Mini-Circuits Characterization Test Board TB-270.
Typical Frequency Response
ATTENUATION (dB)
40
20
Electrical Schematic
R F IN
R F OUT
PCB Land Pattern
3
1
DC
F5
F1 F2 F3 F4
FREQUENCY
F6
Typical Performance Data at 25°C
Insertion Loss
(dB)
0.03
0.09
0.24
0.49
0.66
1.31
2.00
3.08
7.37
15.08
24.45
33.13
31.08
30.50
25.86
20.34
14.21
VSWR
(:1)
1.04
1.03
1.22
1.53
1.14
1.41
1.21
1.74
4.31
9.38
13.49
15.67
17.75
18.50
17.22
16.11
9.85
Frequency
(MHz)
40
500
2000
3600
6000
7200
8000
8150
8350
8550
8730
8850
9500
9600
10500
12300
15000
Suggested Layout,
Tolerance to be within
±.002
Outline Dimensions (
inch
)
mm
A
.126
3.20
H
.087
2.21
B
.063
1.60
J
.024
0.61
C
.037
0.94
K
.122
3.10
D
.020
0.51
L
.024
0.61
E
.032
0.81
M
.087
2.21
F
.009
0.23
N
.012
0.30
G
.169
4.29
P
wt
.071 grams
1.80
.020
Demo Board MCL P/N: TB-270
Suggested PCB Layout (PL-137)
40
LFCN-7200D+
INSERTION LOSS
100
LFCN-7200D+
VSWR
INSERTION LOSS (dB)
35
30
20
15
10
5
0
0
3000
6000
9000
12000
FREQUENCY (MHz)
15000
VSWR
25
10
1
0
3000
6000
9000
12000
15000
FREQUENCY (MHz)
Notes
A.
Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.
B.
Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
C.
The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled
to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp
www.minicircuits.com
P.O. Box 35166, Brooklyn, NY 11235-0003 (718) 934-4500 sales@minicircuits.com
Mini-Circuits
®
REV. OR
M125148
LFCN-7200D+
EDR-8033/4U
RAV/URJ
130829
Page 1 of 1
