POWER INDUCTORS
Military Grade Power Inductors
MS416PJB
■
High temperature materials allow operation in ambient
temperatures up to 155°C.
■
Special construction allows it to pass vibration testing to
80 G and shock testing to 1000 G.
■
Tin-lead (Sn-Pb) termination for the best possible board
adhesion
Core material
Ferrite
Terminations
Tin-lead (63/37) over silver-palladium-platinum-glass frit.
Weight
54 – 64 mg
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
1000/7″ reel; 3500/13″ reel
Plastic tape: 12 mm wide, 0.25 mm thick, 8 mm pocket spacing,
1.32 mm pocket depth
Recommended pick and place nozzle
OD: 4 mm; ID:
≤
2 mm
Inductance
2
Part number
1
MS416PJB331MSZ
MS416PJB681MSZ
MS416PJB102NLZ
MS416PJB152MSZ
MS416PJB222MSZ
MS416PJB332MSZ
MS416PJB472MSZ
MS416PJB562MSZ
MS416PJB682MSZ
MS416PJB103MSZ
MS416PJB153MSZ
MS416PJB223MSZ
MS416PJB333MSZ
MS416PJB473MSZ
MS416PJB683MSZ
MS416PJB104MSZ
MS416PJB124MSZ
MS416PJB154MSZ
MS416PJB184MSZ
MS416PJB224MSZ
MS416PJB334MSZ
MS416PJB474MSZ
MS416PJB564MSZ
MS416PJB684MSZ
MS416PJB824MSZ
MS416PJB105MSZ
MS416PJB155MSZ
MS416PJB185MSZ
MS416PJB225MSZ
MS416PJB335MSZ
(µH)
0.33 ±20%
0.68 ±20%
1.0 ±30%
1.5 ±20%
2.2 ±20%
3.3 ±20%
4.7 ±20%
5.6 ±20%
6.8 ±20%
10 ±20%
15 ±20%
22 ±20%
33 ±20%
47 ±20%
68 ±20%
100 ±20%
120 ±20%
150 ±20%
180 ±20%
220 ±20%
330 ±20%
470 ±20%
560 ±20%
680 ±20%
820 ±20%
1000 ±20%
1500 ±20%
1800 ±20%
2200 ±20%
3300 ±20%
Irms
(A)
6
Isat
(A)
5
DCR SRF
3
4
max
typ 10% 20% 30% 20°C 40°C
(Ohms) (MHz) drop drop drop rise rise
0.023
0.055
0.060
0.070
0.100
0.100
0.175
0.260
0.340
0.350
0.550
0.600
0.825
1.40
1.70
2.40
3.30
3.50
5.00
5.20
7.20
10.0
12.5
13.5
20.0
21.5
35.0
36.0
40.0
76.0
375
220
180
140
115
100
70
60
55
40
30
25
22
19
15
12
11.5
10.0
8.0
7.0
7.0
4.0
3.5
3.0
3.0
3.0
2.5
2.0
1.0
0.95
5.2
3.5
2.8
2.6
2.3
1.3
1.6
1.5
1.3
0.98
0.79
0.74
0.45
0.35
0.30
0.24
0.23
0.21
0.18
0.15
0.14
0.10
0.10
0.10
0.090
0.080
0.090
0.079
0.079
0.074
5.4
3.6
2.9
2.7
2.4
1.4
1.7
1.6
1.3
1.0
0.82
0.78
0.47
0.37
0.32
0.26
0.24
0.22
0.19
0.16
0.14
0.11
0.105
0.105
0.095
0.090
0.090
0.085
0.083
0.078
5.6
3.7
3.0
2.8
2.5
1.4
1.8
1.6
1.4
1.1
0.84
0.79
0.48
0.38
0.33
0.27
0.25
0.23
0.20
0.17
0.15
0.12
0.115
0.110
0.095
0.095
0.090
0.087
0.085
0.080
2.7
1.8
1.7
1.6
1.2
1.45
1.10
0.85
0.80
0.55
0.53
0.52
0.46
0.40
0.35
0.30
0.27
0.25
0.23
0.21
0.17
0.13
0.11
0.11
0.105
0.100
0.087
0.075
0.070
0.050
3.7
2.4
2.4
2.2
1.75
2.00
1.45
1.10
0.98
0.75
0.73
0.70
0.61
0.52
0.46
0.40
0.36
0.32
0.29
0.27
0.225
0.175
0.140
0.135
0.132
0.130
0.115
0.100
0.090
0.065
1. When ordering, please specify
testing
code:
MS416PJB105MSZ
Testing: Z
= Coilcraft Critical Products Environmen-
tal Stress Conditions Testing.
H
= Coilcraft Qual + Coilcraft Hi-Rel Burn-in
P
= Coilcraft Qual + MIL-STD-981 Class S
Group A screening
N
= Coilcraft Qual + MIL-STD-981 Class B
Group A screening
C
= Coilcraft Qual + MIL-STD-981 Class S
Group A screening + MIL-STD-981
Class S Group B qualification
W
= Coilcraft Qual + MIL-STD-981 Class B
Group A screening + MIL-STD-981
Class S Group B qualification
2. Inductance tested at 100 kHz, 0.1 Vrms using an
Agilent/HP 4192A. Inductance at 1 MHz is the same
for parts with SRF
≥10
MHz.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using Agilent/HP 8753ES or
equivalent.
5. DC current that causes the specified inductance drop
from its value without current.
6. Current that causes the specified temperature rise
from 25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components”
before soldering.
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document MS433-1
Revised 05/26/09
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2009
Phone
800-981-0363
Fax
847-639-1508
E-mail
cp@coilcraft.com
Web
www.coilcraft-cps.com
POWER INDUCTORS
MS416PJB Series
Typical L vs Frequency
10000
2200 µH
1000 µH
220 µH
Typical L vs Current
10000
2200 µH
1000
1000
1000 µH
220 µH
100 µH
22 µH
Inductance (µH)
100
100 µH
22 µH
Inductance (µH)
100
10
10 µH
5.6 µH
10
10 µH
5.6 µH
2.2 µH
1 µH
1
2.2 µH
1 µH
1
0.1
0.01
0.1
1
10
0.1
0.01
0.1
1
10
Frequency (MHz)
Current (A)
Current Derating
120
110
100
0.1535 ±0.003
*
3,90 ±0,076
Winding
direction
Percent of rated current
90
80
70
60
50
40
25°C
0.1535 ±0.003
*
3,90 ±0,076
Suggested
Recommended
Land
Pattern
Pattern
0.0473 ±0.004
†
1,20 ±0,10
0.118
3,00
0.090
2,30
45°
typ
0.173
4,40
30
20
10
0
-55 -40
Isat
Irms
-20
0
20
0.123
3,124
0.090
2,30
0.028
0,70
40
60
80
100
120
140 160
0.060
1,52
0.060
1,50
0.123
3,124
0.173
4,40
Ambient temperature (°C)
*
Dimensions are of the case not
including the termination. For maximum
overall dimensions including the
termination, add 0.011 in / 0,28 mm.
†
Height dimension is after mounting. For
maximum height dimension before
mounting, add 0.006 in / 0,152 mm.
Dimensions are in
inches
mm
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document MS433-2
Revised 05/26/09
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2009
Phone
800-981-0363
Fax
847-639-1508
E-mail
cp@coilcraft.com
Web
www.coilcraft-cps.com
