2x5mm TRIANGULAR LED LAMP
L301ED
ORANGE
Features
!
LOW
Description
The Orange source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Orange Light
Emitting Diode.
POWER CONSUMPTION.
!
RELIABLE AND RUGGED.
!
SUITABLE
FOR DIRECTION INDICATOR.
!
I.C. COMPATIBLE.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: DSAB2578
APPROVED : J. Lu
REV NO: V.1
CHECKED : Allen Liu
DATE: MAY/13/2002
DRAWN: Y.G
PAGE: 1 OF 3
Selection Guide
P ar t N o .
Dic e
L en s Ty p e
Iv (m c d )
@ 10 m A
Min .
L301E D
ORANGE (GaAsP / GaP)
ORANGE DIFFUSED
1.0
Ty p .
4.0
V i ew i n g
An g l e
2θ1/2
100°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
A
=25°C
°
Sy m b o l
λ
peak
λ
D
∆λ
1/2
C
V
F
I
R
P ar am et er
Peak Wavelength
Dominate Wavelength
Orange
Orange
D ev i c e
Ty p .
627
625
45
15
2.0
2.5
10
Max .
Un its
nm
nm
nm
pF
V
uA
Tes t Co n d it io n s
I
F
=20mA
I
F
=20mA
I
F
=20mA
V
F
=0V;f=1MHz
I
F
=20mA
V
R
= 5V
Spectral Line Half-width Orange
Capacitance
Forward Voltage
Reverse Current
Orange
Orange
Orange
Absolute Maximum Ratings at T
A
=25°C
°
P ar am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
Or an g e
105
30
160
5
-40
°
C To +85
°C
260
°
C For 5 Seconds
Un its
mW
mA
mA
V
SPEC NO: DSAB2578
APPROVED : J. Lu
REV NO: V.1
CHECKED : Allen Liu
DATE: MAY/13/2002
DRAWN: Y.G
PAGE: 2 OF 3
