TS906C2
(20A)
LOW LOSS SUPER HIGH SPEED RECTIFIER
( 200V / 20A )
Outline drawings, mm
10
+0.5
0.9
±0.3
4.5
±0.2
1.32
1.5 Max
9.3
±0.5
1.2
±0.2
5.08
0.8
—0.1
2.7
+0.2
0.4
+0.2
Features
Surface-mount device
Low V
F
Super high speed switching
High reliability by planer design
JEDEC
EIAJ
1. Gate
2, 4. Drain
3. Source
Connection diagram
Applications
High speed power switching
1
2
4
3
Maximum ratings and characteristics
Absolute maximum ratings
Item
Repetitive peak reverse voltage
Average output current
Surge current
Operating junction temperature
Storage temperature
Symbol
V
RRM
I
O
I
FSM
T
j
T
stg
Square wave, duty=1/2, Tc=112°C
Sine wave 10ms
Conditions
Rating
200
20*
80
-40 to +150
-40 to +150
Unit
V
A
A
°C
°C
*
Average forward current of centertap full wave connection
Electrical characteristics (Ta=25°C Unless otherwise specified )
Item
Forward voltage drop
Reverse current
Reverse recovery time
Thermal resistance
Symbol
V
FM
I
RRM
t
rr
R
th(j-c)
Conditions
I
FM
=10A
V
R
=V
RRM
I
F
=0.1A, I
R
=0.2A, I
rec
=0.05A
Junction to case
Max.
0.98
200
35
2.0*
Unit
V
µA
ns
°C/W
3.0
±0.3
(200V / 20A )
Characteristics
Forward characteristics
100
10000
TS906C2 (20A)
Reverse characteristics
1000
10
I
F
[A]
1
I
R
100
[
µ
A]
10
0.1
0
0.2
0.4
0.6
0.8
1.0
1.2
1
0
50 100
150
200
V
F
[V]
V
R
[V]
Forward power dissipation
15
200
Output current-case temperature
10
150
W
F
[W]
5
T
c
[°C]
100
0
0
5
10
50
0
10
20
I
o
[A]
I
o
[A]
Junction capacitance characteristics
100
100
50
30
Surge capability
50
C
j
[pF]
10
I
FSM
[A]
10
5
5
1
3
5
10
30 50
100
1
1
3
5
10
30
V
R
[V]
[time] (at 50Hz)
