DL5244C datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> DL5244C

DL5244C: DescriptionZener Diode; CategoryDiscrete semiconductor diode; File Size88KB，3 Pages; ManufacturerHY Electronic; Websitehttp://www.hygroup.com.tw

Download Datasheet Parametric View All

DL5244C Overview

Zener Diode

DL5244C Parametric

Parameter Name	Attribute value
Maker	HY Electronic
Reach Compliance Code	unknown
ECCN code	EAR99
Diode type	ZENER DIODE

Preview

Download Datasheet

View All

DL5221B SERIES

SURFACE MOUNT ZENER DIODE

VOLTAGE - 2.4 to 75 Volts

POWER

- 500 mWatts

FEATURES

●

Planar Die Construction

●

500mW Power Dissipation

●

Ideally Suited for Automated Assembly Processes

MINI MELF(DL-35)

MECHANICAL DATA

●

Case: Molded Glass MINI-MELF

●

Terminals: Solderable per MIL-STD-202E, Method 208

●

Polarity: See Diagram Below

●

Approx. Weight: 0.008 grams

●

Mounting Position: Any

Unit :inch(mm)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Parameter

Power Dissipaiton at Tamb = 25℃

Junction Temperature

Storage Temperature Range

Symbol

TOT

Value

500

175

-65to+175

Units

℃

Vaild provided that leads at a distance of 10mm from case are kept at ambient temperature.

Parameter

Thermal Resistance Junciton to Ambient Air

Forward Voltage at IF=200mA

Symbol

θJA

Min

---

Typ

---

Max

0.3

1.1

Units

K/mW

Vaild provided that leads at a distance of 10 mm from case are kept at ambient temperature.
