DCJ
CONNECTOR
Specifications –––––––––––––––––––
DCJ (Large current type)
• Current rating: 6A AC, DC
• Voltage rating: 16V AC, DC
• Temperature range:
-
25˚C to
+
85˚C
(including temperature rise in applying
electrical current)
• Applicable wire: AWG #22×2 wires
DCJ/S type
This is a jack connector for DC power
supply used for handheld devices and
notebook PC.
"Harness type with crimping" is adopted to
prevent from defectives of conventional
product such as "Solder crack" of PC
board mounting types due to an excessive
external force when mating and unmating
operations, and "Poor soldering" of
harness types with solder potting.
High safety is realized.
• Good workability when assembling
connector
• Easy setting to an equipment panel
• For large current (DCJ・
DCJ/S type)
• Compact design (DCJ/A type)
• Current rating: 5A AC, DC (AWG#20)
• Voltage rating: 20V AC, DC
• Temperature range:
-
25˚C to
+
85˚C
(including temperature rise in applying
electrical current)
• Applicable wire: AWG #20
* Contact JST for applicable plug.
DCJ/A type (Compact type)
• Current rating: 2A AC, DC (AWG#26)
• Voltage rating: 6.3V AC, DC
• Temperature range:
-
20˚C to
+
70˚C
(including temperature rise in applying
electrical current)
• Applicable wire: AWG #26 to #28
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Assembly layout
●DCJ
type
●S
type
●A
type
5.3
5.3
14.5
14.5
5.7
15.3
11.4
15
10
11.8
8.15
13.8
φ2.4
φ7.3
φ2.95
φ6.5
Note: The dimensions above should serve as a guideline. Contact JST for details.
1
12
φ1.65
φ4.4
5.3
12
DCJ CONNECTOR
Contact
Pin contact
18.9
Socket contact
11.95
4.3
●DCJ
type
φ2.95
3.5
●DCJ
type
12.9
7.6
4.3
●S
type
11.6
10.3
4.3
●S
type
7.6
4.1
12.9
4.3
φ2.4
●A
type
φ1.65
18.75
3.05
●A
type
3.2
10.6
3.05
2.5
4.65
Type
DCJ type
S type
A type
Model No.
Pin type
SDCJ-21A-3.0
SDCJS-01GE-2.4
SDCJA-002G-P1.65
Material and Finish
Socket type
SDCJ-21A-E6.5
SDCJS-01GE-E5.5
SDCJA-002G-P4.4A
Applicable wire
AWG #
mm
2
0.33
0.5
0.08∼0.13
22
20
26∼28
Insulation O.D.
（mm）
1.3
1.6
0.8∼1.1
Q’ty / reel
Pin type
Socket type
6,000
3,500
10,000
2,500
3,200
10,000
Contact
SDCJ-21A-3.0
SDCJ-21A-E6.5
SDCJS-01GE-2.4
SDCJS-01GE-E5.5
SDCJA-002G-P4.4A
SDCJA-002G-P1.65
Type
DCJ type
Copper alloy, Overall nickel-undercoated, silver-plated (DCJ type)
Copper alloy, Overall nickel-undercoated, gold-plated (S type, A type)
Crimping
machine Crimp applicator
MKS-L
MKS-L
MKS-L
MKS-L
MKS-L
MKS-L
Applicator
Dies
Crimp applicator with dies
MK/SDCJ-21-30 APLMK SDCJ21-30
MK/SDCJ-21-65 APLMK SDCJ21-65
MK/SDCJS-01-24 APLMK SDCJS01-24
MK/SDCJS-01-55 APLMK SDCJS01-55
MK/SDCJA-002-44A APLMK SDCJA002-44A
MK/SDCJA-002-165 APLMK SDCJA002-165
RoHS compliance
S type
AP-K2N
A type
Housing
●DCJ
type
●S
type
●A
type
Holder
●DCJ
type
10.2
●S
type
10.3
15.3
15.3
11.4
15
10
11.8
8.15
5.3
PUSH
11.4
12
φ4.4
●A
type
J S T
5.3
K - A
φ7.3
φ6.5
Type
DCJ type
S type
A type
Model No.
DCJR-02V-A
DCJSR-02V-A
DCJAR-03V-A
Material
Thermoplastic resin
Q’ty / box
150
150
500
Type
DCJ type
S type
A type
Model No.
DCJR-02V-B
DCJSR-02V-B
DCJAR-03V-B
Material
Thermoplastic resin
15.3
Q’ty / box
1,000
1,000
500
RoHS compliance
*Contact JST for applicable plug.
RoHS compliance
