LED Power
ZLF100 SERIES
KEY FEATURES
Open Frame LED Power Supply
With Constant Current & Constant Voltage (C.C+C.V mode)
Universal Input: 100-277 VAC
With P.F.C. Function, PF>0.9
High Efficiency up to 90%
Free Air Convection
Protections: Over Load / Over Voltage / Short Circuit
High Reliability & Double Layered PCB
Ultra Compact Size: 5.0 x 2.5 x 1.3 Inches
3-Years Product Warranty
100 Watts
ELECTRICAL SPECIFICATIONS
All specifications valid at normal input voltage, full load and +25°C after warm-up time unless otherwise stated.
Model No.
Max output wattage
(W)
(Note2)
Voltage
Frequency (Hz)
Input
Power factor
Current (Full load)
Inrush current
Leakage Current
Voltage (V.DC.)
Voltage ADJ Range Setup
Constant Current Operation Voltage (max)
(CC Mode) (Note3)
Voltage Tolerance
Output
Preset Current (mA) (CC Mode)
Current Adjustment Range (mA)
(CC Mode)
Minimum Load (mA)
Line Regulation (100-277VAC) (typ.)
Load Regulation (Min-Max) (typ.)
Ripple & Noise (max)
Efficiency (at 230VAC.)(typ)
Over current protection
Protection
Over voltage protection
Short circuit protection
Input-Output (V.AC)
Isolation
Input-FG
Output-FG
(V.AC)
.(V.AC)
ZLF100-24S
96W
90-295 VAC
50 / 60 Hz
PF>0.9 at Full load (115 VAC / 230 VAC)
1.4A max. (115 VAC) / 0.7A max. (230 VAC)
60 A max. (Cold Start at 230 VAC)
< 0.7 mA max at 240 VAC
24V
22 ~ 27V
15.6~ 24
VDC
±10%
3850
2600~4000
2600
±4%
±5%
2.7Vp-p
89%
Auto recovery
Zener diode clamp
Auto recovery
3750V
1880V
500V
-30°C…+70°C (with derating)
-40°C…+85°C
0.02%/°C
95% RH
>530,000 h @ 25°C (MIL-HDBK-217F)
6.44 x 2.79 x 1.50 Inches
g
Free air convection
UL8750、IEC / EN 61347-2-13、 IEC / EN 61347-1
EN 55015
EN 61547
(Pending)
(Pending)
(Pending)
(Pending)
(163.7 x 71.0 x 38.0 mm ) Tolerance
±0.5
mm
3.6Vp-p
90%
5Vp-p
90%
2450
1720~2650
1720
1750
1150~1770
1150
36V
33 ~ 40V
23.4~36
VDC
54V
49 ~ 58V
35.1~54
VDC
ZLF100-36S
96W
ZLF100-54S
95.58W
Operating temperature
Storage temperature
Environment
Temperature coefficient
Humidity
MTBF
Dimension (L x W x H)
Physical
Safety
Weight
Cooling method
Agency Approvals
EMI
(Conducted & Radiated Emission)
EMS (Noise Immunity)
Harmonic Current
Surge
http://www.archcorp.com.tw
TEL: +886-2-26989508 FAX: +886-2-26981319
EMC
EN 61000-3-2(at Full Load)、EN 61000-3-3
2KV L-L, 4KV L-E
-1-
VER :
PA_0
update :
2012.03.09
LED Power
ZLF100 SERIES
Note:
1. Ripple & Noise are measured at 20MHz of bandwidth with 0.1uF & 47uF parallel capacitor.
2. Please check the derating curve for more details.
100 Watts
3. Input Voltage=115 or 230 VAC。This is the suitable operation region for LED related application.but please reconfirm special electrical requirements
for some specific ststem design.
MECHANICAL DIMENSION
( Top View )
PIN#
1
2
3
4
SINGLE
AC IN (N)
AC IN (L)
+DC OUT
-DC OUT
DERATING
BLOCK DIAGRAM
http://www.archcorp.com.tw
TEL: +886-2-26989508 FAX: +886-2-26981319
-2-
