SERIES
DC1390R
DC1390
DA
SH
NU
MB
High Current Power Line Chokes
Actual Size
Physical Parameters
Inches
A
1.400 to 1.480
B
1.150 Reference
C
0.750 Minimum
D
1.064 Maximum
F
0.200 Reference
G
See Table
Millimeters
35.56 to 37.60
29.21 Reference
19.05 Minimum
27.03 Maximum
5.08 Reference
-153K
-183K
-223K
-273K
-333K
-393K
-473K
-563K
-683K
-823K
-104K
-124K
-154K
-184K
-224K
-274K
-334K
-394K
-474K
-564K
-684K
-824K
-105K
-125K
-155K
-185K
-225K
-275K
-335K
-395K
SERIES DC1390 and DC1390R
15.0
0.006
19.9
18.0
0.008
17.3
22.0
0.009
16.3
27.0
0.010
15.4
33.0
0.011
14.7
39.0
0.012
14.1
47.0
0.018
11.5
56.0
0.019
11.2
68.0
0.021
10.7
82.0
0.023
10.2
100
0.025
9.76
120
0.028
9.23
150
0.040
7.72
180
0.045
7.28
220
0.050
6.90
270
0.056
6.52
330
0.074
5.67
390
0.082
5.39
470
0.114
4.57
560
0.125
4.37
680
0.139
4.14
820
0.154
3.93
1000
0.216
3.32
1200
0.232
3.21
1500
0.324
2.71
1800
0.360
2.57
2200
0.494
2.20
2700
0.555
2.07
3300
0.773
1.76
3900
0.845
1.68
33.3
30.4
28.0
25.9
22.6
21.2
20.0
17.5
16.3
14.9
13.2
12.3
10.8
9.86
9.09
8.05
7.37
6.80
6.20
5.69
5.11
4.70
4.24
3.87
3.45
3.14
2.86
2.58
2.33
2.14
0.081
0.081
0.081
0.081
0.081
0.081
0.072
0.072
0.064
0.064
0.064
0.064
0.057
0.057
0.057
0.057
0.051
0.051
0.046
0.046
0.046
0.046
0.041
0.041
0.036
0.036
0.032
0.032
0.029
0.029
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
Operating Temperature Range
-55°C to +125°C;
(-55°C to +80°C @ full current)
Current Rating at 80° Ambient
45°C Temperature Rise
Maximum Power Dissipation at +80°C
3.30 Watts
Maximum
Inductance
Measured @ 1 kHz with 0 ADC
on Wayne Kerr 3245A, or equivalent
Leads
Solder coated to within 1/16" of Body
Incremental Current
The amount of DC that decreases
the inductance by 5% maximum, relative to the 0 ADC
Dielectric Withstanding Voltage
1000 Vrms Minimum
Mechanical Configuration
Center hole allows for
mounting
Marking
API, 1390 or 1390R, dash number (per table)
and inductance tolerance letter
API
1390
xxxK
Packaging
Bulk only
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com
5/2010
