MAX4835ETT33BD2-T datasheet, PDF

Datasheet> All Categories > Power/power management> The power supply circuit> MAX4835ETT33BD2-T

MAX4835ETT33BD2-T: DescriptionFixed Positive LDO Regulator, 3.3V, 0.165V Dropout, BICMOS, 3 X 3 MM, 0.80 MM HEIGHT, MO-229WEEA, TDFN-6; CategoryPower/power management The power supply circuit; File Size343KB，12 Pages; ManufacturerMaxim; Websitehttps://www.maximintegrated.com/en.html

Download Datasheet Parametric View All

MAX4835ETT33BD2-T Overview

Fixed Positive LDO Regulator, 3.3V, 0.165V Dropout, BICMOS, 3 X 3 MM, 0.80 MM HEIGHT, MO-229WEEA, TDFN-6

MAX4835ETT33BD2-T Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Maxim
Parts packaging code	SON
package instruction	HVSON, SOLCC6,.13,38
Contacts	6
Reach Compliance Code	not_compliant
ECCN code	EAR99
Adjustability	FIXED
Maximum drop-back voltage 1	0.165 V
Nominal dropback voltage 1	0.103 V
Maximum absolute input voltage	6 V
Maximum input voltage	5.5 V
Minimum input voltage	2.5 V
JESD-30 code	S-XDSO-N6
JESD-609 code	e0
length	3 mm
Maximum grid adjustment rate	0.0045%
Humidity sensitivity level	1
Number of functions	1
Output times	1
Number of terminals	6
Working temperatureTJ-Max	125 °C
Working temperature TJ-Min	-40 °C
Maximum output current 1	0.25 A
Maximum output voltage 1	3.366 V
Minimum output voltage 1	3.234 V
Nominal output voltage 1	3.3 V
Package body material	UNSPECIFIED
encapsulated code	HVSON
Encapsulate equivalent code	SOLCC6,.13,38
Package shape	SQUARE
Package form	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE
method of packing	TAPE AND REEL
Peak Reflow Temperature (Celsius)	240
Certification status	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Maximum seat height	0.8 mm
surface mount	YES
technology	BICMOS
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	NO LEAD
Terminal pitch	0.95 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
Maximum voltage tolerance	2%
width	3 mm

Preview

Download Datasheet

View All

19-3373; Rev 0; 7/04

250mA LDO Linear Regulators with

Current-Limiting Switch

General Description

The MAX4834/MAX4835 family of low-dropout (LDO)

linear regulators feature an accurate current-limiting

switch with an integrated

FLAG

RESET

function. These

devices operate from 2.5V to 5.5V and deliver up to

250mA of load current at a preset output voltage. Preset

output voltage levels are 1.8V/2.5V/2.8V/3.0V/3.3V.

The MAX4834/MAX4835 offer a programmable soft-

start control function to eliminate false reset during

startup. The MAX4834 provides a

FLAG

function to noti-

fy the system when the load current exceeds the limit.

The MAX4835 provides a

RESET

function to notify the

system when the output drops below the threshold.

Additionally, reverse-current protection prevents cur-

rent flowing from the output to the input. Other features

include a low 90µA quiescent current, a 0.1µA shut-

down current.

The MAX4834/MAX4835 are available in space-saving

6-pin SOT23 and TDFN packages. Each device is speci-

fied over the -40°C to +85°C extended temperature

range. Contact factory for other programmed output volt-

age versions from 1.5V to 3.3V in 100mV increments.

For pin-compatible 100mA versions of this device, refer

to the MAX4832/MAX4833. For pin-compatible 500mA

versions of this device, refer to the MAX4836/MAX4837.

♦

Accurate Current Limit

♦

Preset Output Voltages: 1.8V/2.5V/2.8V/3.0V/3.3V

♦

2.5V to 5.5V Supply Voltage Range

♦

Adjustable Soft-Start

♦

Low Dropout Voltage

♦

Thermal Shutdown

♦

Reverse-Current Protection

♦

Shutdown Output Discharge (MAX4835)

♦

Low 90µA Supply Current

♦

Ultra-Low 0.1µA Shutdown Current

♦

FLAG

and Latch Off (MAX4834) or

RESET

(MAX4835)

♦

Tiny SOT23 and TDFN (3mm x 3mm) Packages

Features

♦

Guaranteed Minimum 250mA Load Current

MAX4834/MAX4835

Ordering Information

PART

MAX4834EUTxy_-T*

MAX4834ETTxy_-T

MAX4835EUTxy_dd-T*

MAX4835ETTxy_dd-T

TEMP RANGE

-40°C to +85°C

PIN-PACKAGE

6 SOT23-6

6 TDFN-6

6 SOT23-6

6 TDFN-6

Applications

SDIO Ports and Devices

USB Ports and Devices

PDAs and Palmtop Devices

Notebook Computers

Cell Phones

GPS Systems

Pin Configurations

TOP VIEW

OUT

RESET

(FLAG)

GND

SHDN

MAX4834/MAX4835

EXPOSED PADDLE

Note:

“xy” are placeholders for the output voltage levels of the

devices. Insert the values found in Table 1 at the end of this doc-

ument in the place of “xy”. The “_” is a placeholder for either the

RESET

or the

FLAG

feature. Insert “B” in the place of “_” for

RESET

and “C” for

FLAG

. “dd” is a placeholder for the reset

timeout period. Insert the values found in Table 2 in the place of

“dd.” For example, MAX4835EUT18BD2 has a 1.8V output volt-

age,

RESET

feature, and a 30ms reset timeout period. Note that

“dd” applies only to the devices with

RESET

option and does not

apply to the devices with

FLAG

option. For devices with the

FLAG

option, leave dd blank. Standard versions require a mini-

mum order increment of 2.5k units. Nonstandard versions must

be ordered in 10k unit increments. Contact factory for availability.

*Future

product—contact factory for availability.

Tables 1 and 2 and Selector Guide appear at end of data

sheet.

TDFN

( ) MAX4834ETTxyC ONLY.

Pin Configurations continued at end of data sheet.

________________________________________________________________

Maxim Integrated Products

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at

1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
