BZT52-C15S Overview

15 V, 0.2 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE

Preview

Download Datasheet

View All

200mW

SURFACE MOUNT SILICON ZENER DIODES

2.4V~51V

SOD-323 PACKAGE

FEATURES

• Planar Die construction

• 200mW Power Dissipation

.016(0.40)

.010(0.25)

BZT52-C2V4S

THRU

BZT52-C51S

Pb Free Product

SOD-323

.106(2.70)

.055(1.40)

.045(1.15)

.091(2.30)

.071(1.80)

.063(1.60)

.039(1.00)

.031(0.80)

• Zener Voltages from 2.4~51V

• Ideally Suited for Automated Assembly Processes

MECHANICAL DATA

• Case: SOD-323 , Molded Plastic

• Terminals: Solderable per MIL-STD-750, Method 2026

• Polarity: See Diagram Below

• Approx. Weight: 0.0046 grams

• Mounting Position: Any

.007(0.18)MAX.

.004(0.10)MAX.

ORDER INFORMATION

•

.016(0.40)

.010(0.25)

.010(0.25)MIN.

Packing information

-T1 3K per 7" plastic Reel

Product Type Symbol

RoHS product for packing code suffix "G"

Halogen free product for packing code suffix "H"

Dimensions in inches and (millimeters)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

PARAMETER

Power Dissipation

at Tamb=25℃

SYMBOL

TOT

VALUE

200

-55 to +150

UNIT

℃

Operating Junction and Storage Temperature Range

Valid provided that leads at a distance of 10mm from case kept at ambient temperature.

NOTE :

A. Mounted on 5.0mm

(.013mm thick) land areas.

2011-09

WILLAS ELECTRONIC CORP.
