ZB4PD1-500-S+ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> ZB4PD1-500-S+

ZB4PD1-500-S+: DescriptionCombiner, 5MHz Min, 500MHz Max, 1.5dB Insertion Loss-Max, ROHS COMPLIANT, CASE UU188; CategoryWireless rf/communication Radio frequency and microwave; File Size205KB，1 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com; Environmental Compliance

Download Datasheet Parametric Compare View All

ZB4PD1-500-S+ Overview

Combiner, 5MHz Min, 500MHz Max, 1.5dB Insertion Loss-Max, ROHS COMPLIANT, CASE UU188

ZB4PD1-500-S+ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Mini-Circuits
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	SMA
Characteristic impedance	50 Ω
structure	COAXIAL
Maximum input power (CW)	30 dBm
Maximum insertion loss	1.5 dB
Maximum operating frequency	500 MHz
Minimum operating frequency	5 MHz
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
RF/Microwave Device Types	COMBINER
Maximum voltage standing wave ratio	1.14

Preview

Download Datasheet

View All

Coaxial

Power Splitter/Combiner

4 Way-0°

Operating Temperature

Storage Temperature

Power Input (as a splitter)

Internal Dissipation

ZB4PD1-500+

50Ω

-55°C to 100°C

5 to 500 MHz

Features

• wideband, 5 to 500 MHz

• high isolation, 34 dB typ.

• rugged, shielded case

SMA version shown

CASE STYLE: UU188

Connectors Model

Price

BNC

ZB4PD1-500+

$79.95

SMA

ZB4PD1-500-S+

$94.95

N-TYPE

ZB4PD1-500-N+

$94.95

Maximum Ratings

1W max.

0.250W max.

Permanent damage may occur if any of these limits are exceeded.

Applications

Qty.

(1-9)

Coaxial Connections

SUM PORT

PORT 1

PORT 2

PORT 3

PORT 4

• VHF/UHF

• receivers/transmitters

+ RoHS compliant in accordance

with EU Directive (2002/95/EC)

The +Suffix has been added in order to identify RoHS

Compliance. See our web site for RoHS Compliance

methodologies and qualifications.

Electrical Specifications

FREQ.

RANGE

(MHz)

-f

5-500

Typ. Min.

ISOLATION

(dB)

Typ. Min.

INSERTION LOSS (dB)

ABOVE 6.0 dB

Typ. Max.

0.4

1.0

Typ. Max.

0.5

0.9

Typ. Max.

0.9

1.5

PHASE

UNBALANCE

(Degrees)

Max.

AMPLITUDE

UNBALANCE

(dB)

Max.

0.2

Max.

0.2

Max.

0.4

Outline Drawing

L = low range [f

to 10 f

]

M = mid range [10 f

to f

/2]

U = upper range [f

/2 to f

]

Typical Performance Data

Freq.

(MHz)

S-1

5.00

30.00

50.00

100.00

130.00

150.00

180.00

200.00

230.00

250.00

290.00

350.00

400.00

450.00

500.00

6.34

6.32

6.34

6.39

6.44

6.47

6.44

6.50

6.53

6.55

6.59

6.63

6.69

6.77

Insertion Loss

(dB)

S-2

6.35

6.32

6.34

6.39

6.43

6.46

6.44

6.51

6.54

6.56

6.59

6.64

6.72

6.81

Amp.

Unbal.

(dB)

S-4

6.33

6.32

6.35

6.38

6.43

6.46

6.43

6.48

6.51

6.53

6.58

6.60

6.67

6.75

0.01

0.03

0.02

0.04

0.05

0.06

Isolation

(dB)

1-2

52.83

46.48

43.68

38.83

36.86

35.87

34.55

33.82

32.96

32.54

31.75

31.02

30.73

30.66

30.85

VSWR VSWR VSWR VSWR VSWR

3-4

50.23

44.89

41.92

36.88

34.90

33.83

32.40

31.75

30.74

30.22

29.34

28.37

27.85

27.53

27.37

1.08

1.05

1.07

1.05

1.08

1.06

1.08

1.10

1.11

1.10

1.14

1.11

1.12

1.09

1.08

1.07

1.06

1.05

1.03

1.02

1.01

1.12

1.09

1.10

1.08

1.09

1.07

1.04

1.06

1.05

1.04

1.01

1.02

1.13

1.09

1.10

1.08

1.10

1.09

1.05

1.06

1.07

1.04

1.03

1.01

1.13

1.09

1.10

1.08

1.10

1.09

1.05

1.06

1.07

1.04

1.03

1.02

S-3

6.33

6.31

6.34

6.39

6.43

6.47

6.43

6.49

6.52

6.55

6.59

6.62

6.68

6.71

6.79

2-3

40.68

40.23

39.45

37.13

35.97

35.35

34.35

33.88

33.12

32.76

32.00

31.24

30.84

30.70

30.77

Outline Dimensions (

inch

)

INSERTION LOSS (dB)

ZB4PD1-500+

INSERTION LOSS

7.4

ZB4PD1-500+

ISOLATION

ISOLATION (dB)

1-2(dB)

2-3(dB)

3-4(dB)

3.50

88.90

.125

3.18

2.13

54.10

1.75

44.45

.88

22.35

.44

11.18

.150

3.81

.89

22.61

3.350

85.09

1.06

26.92

grams

260

S-1(dB)

7.0

6.6

6.2

5.8

100

200

S-3(dB)

300

400

500

100

200

300

400

500

FREQUENCY (MHz)

ZB4PD1-500+

VSWR

1.80

#S-VSWR

1.60

VSWR

1.40

1.20

1.00

100

200

300

400

500

FREQUENCY (MHz)

#1-VSWR

#3-VSWR

electrical schematic

ISO 9001 ISO 14001 AS 9100

CERTIFIED

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661

The Design Engineers Search Engine

IF/RF MICROWAVE COMPONENTS

Mini-Circuits

For detailed performance specs

& shopping online see web site

Provides ACTUAL Data Instantly at

minicircuits.com

Notes: 1.

Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.

Electrical specifications

and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.

The parts covered by this specification sheet are subject to

Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard

Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.

REV. D

M121747

ZB4PD1-500+

HY/TD/CP/AM

090827

ZB4PD1-500-S+ Related Products

	ZB4PD1-500-S+	ZB4PD1-500-N
Description	Combiner, 5MHz Min, 500MHz Max, 1.5dB Insertion Loss-Max, ROHS COMPLIANT, CASE UU188	Combiner, 5MHz Min, 500MHz Max, 1.5dB Insertion Loss-Max, CASE UU188
Is it lead-free?	Lead free	Contains lead
Is it Rohs certified?	conform to	incompatible
Maker	Mini-Circuits	Mini-Circuits
Reach Compliance Code	unknown	unknown
Other features	SMA	N
Characteristic impedance	50 Ω	50 Ω
structure	COAXIAL	COAXIAL
Maximum input power (CW)	30 dBm	30 dBm
Maximum insertion loss	1.5 dB	1.5 dB
Maximum operating frequency	500 MHz	500 MHz
Minimum operating frequency	5 MHz	5 MHz
Maximum operating temperature	100 °C	100 °C
Minimum operating temperature	-55 °C	-55 °C
RF/Microwave Device Types	COMBINER	COMBINER
Maximum voltage standing wave ratio	1.14	1.14
