HTC210-471L-RC datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> HTC210-471L-RC

HTC210-471L-RC: DescriptionGeneral Purpose Inductor, 470uH, 15%, 1 Element, ROHS COMPLIANT; CategoryPassive components inductor; File Size1MB，1 Pages; ManufacturerALLIED [Allied Electronics]; Environmental Compliance

Download Datasheet Parametric View All

HTC210-471L-RC Overview

General Purpose Inductor, 470uH, 15%, 1 Element, ROHS COMPLIANT

HTC210-471L-RC Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	ALLIED [Allied Electronics]
Reach Compliance Code	compliant
ECCN code	EAR99
DC Resistance	0.28 Ω
Nominal inductance(L)	470 µH
Inductor Applications	HIGH CURRENT INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Number of functions	1
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Maximum rated current	1.6 A
Shape/Size Description	CYLINDRICAL PACKAGE
shield	NO
surface mount	NO
Terminal location	RADIAL
Terminal shape	WIRE
Test frequency	0.001 MHz
Tolerance	15%

Preview

Download Datasheet

View All

RoHS

Toroidal Chokes

TC210

Dimensions:

Inches

(mm)

0.45

MAX

(11.43)

0.86

MAX

(21.84)

Tin lead to coil

0.50

(12.70)

Vertical Mount

Horizontal Mount

Allied

Part

Number

Inductance Tolerance

(µH)

(%)

@ 1KHZ

L(µH)

I rated

IDC

(A)

DCR

(Ω)

MAX

DIM

(Nom) (Nom) (Nom)

Features

•

Low Magnetic Radiation

Low Core Loss

High current capacity up to 10A

Available in Horizontal or Vertical configuration

Optional Tape Cover

Cross to Miller / Bourns 2100

Electrical

Inductance Range:

10µh to 1000µh

Additional values available

Tolerance:

15% over entire range

Test Frequency:

1KHz

Operating Temp:

-55ºC ~ +105ºC

Temp Rise:

∆

T=30ºC Typical at rated IDC

Part temperature should not exceed 125ºC

including temperature rise.

(

)TC210-100L-RC

)TC210-120L-RC

)TC210-150L-RC

)TC210-180L-RC

)TC210-220L-RC

)TC210-270L-RC

)TC210-330L-RC

)TC210-390L-RC

)TC210-470L-RC

)TC210-560L-RC

)TC210-680L-RC

)TC210-101L-RC

)TC210-121L-RC

)TC210-151L-RC

)TC210-181L-RC

)TC210-221L-RC

)TC210-271L-RC

)TC210-331L-RC

)TC210-391L-RC

)TC210-471L-RC

)TC210-561L-RC

)TC210-681L-RC

)TC210-821L-RC

)TC210-102L-RC

100

121

150

180

220

270

330

390

470

560

680

820

1000

6.3

7.4

10.2

11.9

14.2

19.1

22.8

26.4

34.7

40.6

48.3

75.2

88.5

84.3

113.1

134.4

181.6

216.3

250.1

293.8

341.5

403.2

472.8

559.2

10.8

10.3

7.7

7.4

7.0

5.3

5.0

4.8

3.6

3.4

3.3

2.4

2.2

3.4

2.6

2.4

1.8

1.7

1.6

1.5

1.4

1.3

.006

.007

.012

.013

.015

.026

.029

.032

.055

.060

.067

.130

.150

.062

.110

.120

.210

.230

.250

.280

.300

.330

.370

.400

.34

.33

.32

.31

.35

.34

.33

.35

.37

.77

.76

.75

.74

.79

.77

.76

.79

.81

.053

.042

.034

.027

.022

.034

.027

.022

Test Equipment

(L):

100 LCR meter or equivalent

DCR:

Chen Hwa 502

Please specify Vertical or Horizontal Mount

by placing a V or H at the beginning of the part number,

i.e. VTC210-100L (Vertical Mount). All specifications subject to change without notice.

Physical

Packaging:

Bulk

Marking:

None

714-665-1140

ALLIED COMPONENTS INTERNATIONAL

REVISED 6/25/10

www.alliedcomponents.com
