APL5156
High Input Voltage, Low Quiescent Current, 150mA LDO Regulator
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Wide Operating Voltage : 6.5V~25V
Ultra Low Ground Current : 70µA
High Output Accuracy :
±
2% Over Temperature
Excellent Load/Line Transient
Low Dropout Voltage : 1900mv @ 150mA
Fixed Output Voltages for 5V/3.3V or Adjustable
Voltage
Built-In Reverse Battery Protection
Built-In Reverse Leakage Protection
Built-In Current-Limit Protection
Built-In Over-Temperature Protection
Zero Shutdown Current
Internal Soft-Start Function 0.5ms~1.5ms (max)
Over Temperature
POR Scheme to Prevent V
OUT
Spike
Stable with Aluminum, Tantalum, or Ceramic
Capacitors
SOT-23-5, SOT-89, and SOP-8P Packages
Lead Free and Green Devices Available
(RoHS Compliant)
General Description
The APL5156 is a low ground current linear regulator,
which operates with input voltage from 6.5V to 25V and
delivers output current up to 150mA. Typical dropout volt-
age is only 1.9V at 150mA loading. This combination of
the high voltage and the low ground current makes the
APL5156 ideal for USB and portable devices, using 2-
cell or 3-cell Li-Ion battery inputs.
The APL5156 is stable with aluminum, tantalum, and
ceramic capacitors. It requires a 2.2µF or greater capaci-
tor for stability.
The APL5156 has many protection functions, including
over-temperature, current-limit, reverse battery, and
reverse leakage protections which prevent the device from
thermal over-load, current over-load, reverse connection
of the battery and output current reversing to the VIN.
The APL5156 regulator is available in miniature SOT-23-
5, SOT-89, and SOP-8P packages.
Simplified Application Circuit
VIN
VOUT
Applications
•
•
•
•
USB Power Supply
Keep-Alive Supply in Notebook and Portable
Computers
Logic Supply for High-Voltage Batteries
Battery Powered Systems
APL5156
C
IN
1µF
EN
GND
ADJ
C
OUT
2.2µF
Adjustable Output Voltage (SOT-23-5/SOP-8P)
Pin Configuration
SOT-23-5
VIN 1
GND 2
EN 3
5 VOUT
4 NC/ADJ
GND 1
VIN 2
VOUT 3
TAB: VIN
SOT-89
VOUT
NC
NC
NC/ADJ
1
2
3
4
SOP-8P
8
7
6
5
VIN
GND
NC
EN
Thermal Pad (connected to GND
plane for better dissipation)
ANPEC reserves the right to make changes to improve reliability or manufacturability without notice, and
advise customers to obtain the latest version of relevant information to verify before placing orders.
Copyright
©
ANPEC Electronics Corp.
Rev. A.6 - Oct., 2009
1
www.anpec.com.tw
APL5156
Ordering and Marking Information
APL5156
Assembly Material
Handling Code
Temperature Range
Package Code
Voltage Code
Package Code
B : SOT-23-5
D : SOT-89
KA : SOP-8P
Operating Ambient Temperature Range
I : -40 to 85
o
C
Handling Code
TR : Tape & Reel
Voltage Code :
33 : 3.3V
50 : 5.0V
Blank : Adjustable Version
Assembly Material
G : Halogen and Lead Free Device
X - Date Code
APL5156
B:
L56X
APL5156
33B :
56RX
56ZX
APL5156
XXXXX33
APL5156
XXXXX
X - Date Code
;
33 - 3.3V
APL5156
50B :
X - Date Code ;
50 - 5.0V
APL5156
D:
XXXXX - Date Code
;
33 - 3.3V
APL5156
KA :
XXXXX - Date Code
Note: ANPEC lead-free products contain molding compounds/die attach materials and 100% matte tin plate termination finish; which
are fully compliant with RoHS. ANPEC lead-free products meet or exceed the lead-free requirements of IPC/JEDEC J-STD-020D for
MSL classification at lead-free peak reflow temperature. ANPEC defines “Green” to mean lead-free (RoHS compliant) and halogen
free (Br or Cl does not exceed 900ppm by weight in homogeneous material and total of Br and Cl does not exceed 1500ppm by
weight).
Absolute Maximum Ratings
Symbol
V
IN
,V
EN
VIN, EN to GND Voltage
EN to VIN Voltage
V
OUT
,V
ADJ
VOUT, ADJ to GND Voltage
VOUT, ADJ to VIN Voltage
P
D
T
J
T
STG
T
SDR
Power Dissipation
Operating Junction Temperature
Storage Temperature Range
(Note 1)
Rating
- 27 to 27
-27 to 27
- 0.3 to 27
-27 to 27
Internally Limited
-40 to 125
-65 to +150
260
Unit
V
V
V
V
W
o
o
o
Parameter
C
C
C
Maximum Lead Soldering Temperature, 10 Seconds
Note 1: Absolute Maximum Ratings are those values beyond which the life of a device may be impaired. Exposure to absolute
maximum rating conditions for extended periods may affect device reliability.
Thermal Characteristics
Symbol
Parameter
Thermal Resistance-Junction to Ambient
θ
JA
(Note 2)
Typical Value
SOT-23-5
SOT-89
SOP-8P
235
180
50
Unit
o
C/W
Copyright
©
ANPEC Electronics Corp.
Rev. A.6 - Oct., 2009
2
www.anpec.com.tw
APL5156
Thermal Characteristics (Cont.)
Symbol
Parameter
Thermal Resistance-Junction to Case
130
SOT-23-5
38
SOT-89
20
SOP-8P
Note 2:
θ
JA
is measured with the component mounted on a high effective thermal conductivity test board in free air.
θ
JC
o
Typical Value
Unit
C/W
Electrical Characteristics
Unless otherwise noted, these specifications apply over V
IN
=V
OUT
+2.5V, C
IN
=1µF, C
OUT
=2.2µF, T
A
=-40
o
C to 85
o
C. Typical values refer
to T
A
=25
o
C.
Symbol
V
IN
V
OUT
Parameter
Input Voltage
Output Voltage Accuracy
Output Voltage Range
I
OUT
=0.1mA
I
Q
Quiescent Current
I
OUT
=50mA
I
OUT
=100mA
I
OUT
=150mA
I
OUT
V
REF
REG
LINE
REG
LOAD
Load Current Range
Reference Voltage
Line Regulation
Load Regulation
V
OUT
+2.5V<V
IN
<25V, I
OUT
=1mA
0.1mA<I
OUT
<150mA
I
OUT
=0.1mA
V
DROP
Dropout Voltage
I
OUT
=50mA
I
OUT
=100mA
I
OUT
=150mA
POWER-ON-RESET (POR)
Rising V
IN
Threshold
PROTECTIONS
Over-Temperature Shutdown
OTS
I
LIMIT
I
SHORT
Over-Temperature Shutdown
Hysteresis
Circuit Current Limit
Short Current
Output Leakage,
Reverse Polarity Input
SOFT-START AND SHUTDOWN
T
SS
V
EN
I
EN
I
QSHDN
Soft-Start Interval
Input High Voltage
Input Low Voltage
EN Pin Input Bias Current
Shutdown Supply Current
V
EN
=25V
EN=Low, V
IN
=19V
From enable to V
OUT
= 90%
0.5
2.5
-
-
-
1
-
-
1
0.1
1.5
-
0.6
5
1
ms
V
µA
µA
V
IN
=V
OUT
+2.5V
V
OUT
=0V
Load=500Ω,V
IN
= -15V, EN=GND
Load=500Ω, V
IN
=V
EN
= -15V
-
-
250
-
-
-
150
10
350
50
-3
-4
-
-
500
-
-5
-5
o
Test Conditions
APL5156
Min.
6.5
-2
3
-
-
-
-
0
-2%
-
-
-
-
-
-
4
Typ.
-
-
-
70
0.5
2
5
-
1.24
0.01
0.4
1300
1600
1700
1900
5
Max.
25
2
20
100
1
3.5
7
150
+2%
-
1
1900
2000
2100
2300
6
Unit
V
%
V
µA
mA
mA
mA
mA
V
%
%
mV
V
C
C
o
mA
mA
µA
mA
Copyright
©
ANPEC Electronics Corp.
Rev. A.6 - Oct., 2009
3
www.anpec.com.tw
