DR-15_11: Description15W Single Output Industrial DIN Rail Power Supply; File Size474KB，2 Pages; ManufacturerMEAN WELL; Websitehttp://www.meanwell.com

Download Datasheet View All

DR-15_11 Overview

15W Single Output Industrial DIN Rail Power Supply

Preview

Download Datasheet

View All

15W Single Output Industrial DIN Rail Power Supply

■



‧



DR-15

series

SPECIFICATION

MODEL

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

OUTPUT

VOLTAGE ADJ. RANGE

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

HOLD UP TIME (Typ.)

VOLTAGE RANGE

FREQUENCY RANGE

INPUT

EFFICIENCY (Typ.)

AC CURRENT (Typ.)

INRUSH CURRENT (Typ.)

OVERLOAD

PROTECTION

OVER VOLTAGE

WORKING TEMP.

WORKING HUMIDITY

ENVIRONMENT STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

SAFETY STANDARDS

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

EMC EMISSION

EMC IMMUNITY

MTBF

OTHERS

NOTE

Note.5

‧



‧



‧



‧

Ⅱ

‧



‧



‧



‧



DR-15-5

2.4A

0 ~ 2.4A

12W

4.75 ~ 5.5V

±1.0%

1000ms, 50ms/230VAC

70ms/230VAC

85 ~ 264VAC

47 ~ 63Hz

77%

DR-15-12

12V

1.25A

0 ~ 1.25A

15W

120mVp-p

10.8 ~ 13.2V

±1.0%

1000ms, 50ms/115VAC at full load

16ms/115VAC at full load

120 ~ 370VDC

84%

DR-15-15

15V

0 ~ 1A

15W

120mVp-p

13.5 ~ 16.5V

±1.0%

DR-15-24

24V

0.63A

0 ~ 0.63A

15.2W

150mVp-p

21.6 ~ 26.4V

±1.0%

RIPPLE & NOISE (max.)

Note.2

80mVp-p

VOLTAGE TOLERANCE

Note.3

±2.0%

83.5%

85%

0.88A/115VAC

0.48A/230VAC

COLD START 35A/115VAC

65A/230VAC

105 ~ 160% rated output power

Protection type :

Constant current limiting, recovers automatically after fault condition is removed

5.75 ~ 6.75V

13.8 ~ 16.2V

17.25 ~ 20.25V

27.6 ~ 32.4V

Protection type :

Shut off o/p voltage, clamping by zener diode

-20 ~ +60℃ (Refer to "Derating Curve")

20 ~ 90% RH non-condensing

-40 ~ +85℃, 10 ~ 95% RH

±0.03%/℃

(0 ~ 50℃)

10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6

UL60950-1, TUV EN60950-1 approved, design refer to EN50178

I/P-O/P:3KVAC

I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH

Compliance to EN55011, EN55032 (CISPR32), EN61204-3 Class B, EN61000-3-2,-3

Compliance to EN61000-4-2, 3, 4, 5, 6, 8, 11, EN55024, EN61000-6-2, EN61204-3, heavy industry level, criteria A

1172.3K hrs min. MIL-HDBK-217F (25℃)

25*93*56mm (W*H*D)

0.1Kg; 140pcs/15Kg/0.92CUFT

SAFETY &

EMC

(Note 4)

DIMENSION

PACKING

℃













File Name:DR-15-SPEC 2017-07-07
