200W Single Output with PFC Function
HRP-200
series
■
Features :
Universal AC input / Full range
Built-in active PFC function, PF>0.95
High efficiency up to 89%
Withstand 300VAC surge input for 5 seconds
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Built-in constant current limiting circuit
1U low profile 38mm
Built-in remote sense function
5 years warranty
Bauar t gepruft
Sicherheit
egel ma ge
od
o s
be wac
g
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
VOLTAGE ADJ. RANGE
HRP-200-3.3
3.3V
40A
0 ~ 40A
132W
HRP-200-5
5V
35A
0 ~ 35A
175W
90mVp-p
4.3 ~ 5.8V
±2.0%
±0.5%
±1.0%
HRP-200-7.5
7.5V
26.7A
0 ~ 26.7A
200.3W
100mVp-p
6.8 ~ 9V
±2.0%
±0.5%
±1.0%
HRP-200-12
12V
16.7A
0 ~ 16.7A
200.4W
120mVp-p
10.2 ~ 13.8V
±1.0%
±0.3%
±0.5%
HRP-200-15
15V
13.4A
0 ~ 13.4A
201W
150mVp-p
13.5 ~ 18V
±1.0%
±0.3%
±0.5%
HRP-200-24
24V
8.4A
0 ~ 8.4A
201.6W
150mVp-p
21.6 ~ 28.8V
±1.0%
±0.2%
±0.5%
36V
5.7A
www. tuv.com
ID 2000000000
HRP-200-36
HRP-200-48
48V
4.3A
0 ~ 4.3A
206.4W
250mVp-p
40.8 ~ 55.2V
±1.0%
±0.2%
±0.5%
0 ~ 5.7A
205.2W
250mVp-p
28.8 ~ 39.6V
±1.0%
±0.2%
±0.5%
RIPPLE & NOISE (max.)
Note.2
80mVp-p
2.8 ~ 3.8V
VOLTAGE TOLERANCE
Note.3
±2.0%
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
±0.5%
±1.5%
16ms/230VAC
1000ms, 50ms/230VAC
2500ms, 50ms/115VAC at full load
16ms/115VAC at full load
120 ~ 370VDC
PF>0.99/115VAC at full load
86%
88%
88%
88%
89%
89%
1.1A/230VAC
70A/230VAC
Note.5
85 ~ 264VAC
VOLTAGE RANGE
FREQUENCY RANGE
47 ~ 63Hz
POWER FACTOR (Typ.)
INPUT
EFFICIENCY (Typ.)
AC CURRENT (Typ.)
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
OVERLOAD
PROTECTION
OVER VOLTAGE
OVER TEMPERATURE
WORKING TEMP.
PF>0.95/230VAC
80%
2.1A/115VAC
35A/115VAC
<1.2mA / 240VAC
84%
105 ~ 135% rated output power
Protection type : Constant current limiting, recovers automatically after fault condition is removed
6 ~ 7V
9.4 ~ 10.9V
14.4 ~ 16.8V 18.8 ~ 21.8V 30 ~ 34.8V
41.4 ~ 48.6V
3.96 ~ 4.62V
Protection type : Shut down o/p voltage, re-power on to recover
Shut down o/p voltage, recovers automatically after temperature goes down
-40 ~ +70
℃
(Refer to "Derating Curve")
57.6 ~ 67.2V
20 ~ 90% RH non-condensing
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
-40 ~ +85
℃
, 10 ~ 95% RH
TEMP. COEFFICIENT
±
0.03%/
℃
(0 ~ 50
℃
︶
VIBRATION
10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes
UL60950-1, TUV EN60950-1,
EAC TP TC 004
approved
SAFETY STANDARDS
SAFETY & WITHSTAND VOLTAGE
ISOLATION RESISTANCE
EMC
(Note 4)
I/P-O/P:3KVAC
I/P-FG:2KVAC
O/P-FG:0.5KVAC
EMC EMISSION
EMC IMMUNITY
MTBF
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25
℃
/ 70% RH
Compliance to EN55032 (CISPR32) Class B, EN61000-3-2,-3, EAC TP TC 020
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, heavy industry level, criteria A, EAC TP TC 020
209.4K hrs min.
MIL-HDBK-217F (25
℃
)
199*98*38mm (L*W*H)
0.77Kg; 18pcs/14.9Kg/0.9CUFT
OTHERS
NOTE
DIMENSION
PACKING
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25
℃
of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on
a 360mm*360mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to
perform these EMC tests, please refer to EMI testing of component power supplies. (as available on http://www.meanwell.com)
5. Derating may be needed under low input voltages. Please check the derating curve for more details.
6. The ambient temperature derating of 3.5
℃
/1000m with fanless models and of 5
℃
/1000m with fan models for operating altitude higher than 2000m(6500ft)
.
File Name:HRP-200-SPEC 2018-01-12
