150W Single Output Switching Power Supply
Features :
NES-150
series
AC input range selectable by switch
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
LED indicator for power on
100% full load burn-in test
High efficiency, long life and high reliability
2 years warranty
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
VOLTAGE ADJ. RANGE
VOLTAGE TOLERANCE
Note.3
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE
FREQUENCY RANGE
INPUT
EFFICIENCY (Typ.)
AC CURRENT (Typ.)
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
OVERLOAD
PROTECTION
OVER VOLTAGE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
SAFETY &
EMC
(Note 6)
Note.4
Note.5
NES-150-3.3
3.3V
30A
0 ~ 30A
99W
3.2 ~ 3.5V
3.0%
0.5%
2.0%
24ms/230VAC
47 ~ 63Hz
73%
NES-150-5
5V
26A
0 ~ 26A
130W
80mVp-p
4.75 ~ 5.5V
2.0%
0.5%
1.0%
NES-150-7.5
7.5V
20A
0 ~ 20A
150W
120mVp-p
7.13 ~ 8.3V
1.0%
0.5%
0.5%
NES-150-9
9V
16.7A
0 ~ 16.7A
150W
120mVp-p
8.55 ~ 9.9V
1.0%
0.5%
0.5%
NES-150-12
12V
12.5A
0 ~ 12.5A
150W
120mVp-p
11.4 ~ 13.5V
1.0%
0.5%
0.5%
NES-150-15
15V
10A
0 ~ 10A
150W
120mVp-p
NES-150-24
24V
6.5A
0 ~ 6.5A
156W
120mVp-p
NES-150-48
48V
3.3A
0 ~ 3.3A
158.4W
200mVp-p
45.6 ~ 52.8V
1.0%
0.5%
0.5%
RIPPLE & NOISE (max.)
Note.2
80mVp-p
14.25 ~ 16.5V 22.8 ~ 27.6V
1.0%
1.0%
0.5%
0.5%
0.5%
0.5%
Note.7
800ms, 20ms/230VAC
1200ms, 30ms/115VAC at full load
254 ~ 373VDC
83%
83%
83%
86%
86%
20ms/115VAC at full load
90 ~ 132VAC / 180 ~ 264VAC selected by switch
78%
80%
3A/115VAC
2A/230VAC
COLD START 45A/230VAC
<2mA / 240VAC
110 ~ 150% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
3.8 ~ 4.65V
5.75 ~ 6.75V 8.6 ~ 10.1V
10.4 ~ 12.2V 13.8 ~ 16.2V 17.25 ~ 20.25V 27.6 ~ 32.4V
Protection type : Hiccup mode, recovers automatically after fault condition is removed
-20 ~ +60
(Refer to output load derating curve)
20 ~ 90% RH non-condensing
-40 ~ +85 , 10 ~ 95% RH
0.03%/ (0 ~ 50 )
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
UL60950-1, TUV EN60950-1,GB4943 approved
I/P-O/P:3KVAC
I/P-FG:1.5KVAC
O/P-FG:0.5KVAC
55.2 ~ 64.8V
WITHSTAND VOLTAGE
ISOLATION RESISTANCE
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC 70% RH
EMI CONDUCTION & RADIATION
Compliance to EN55022 (CISPR22) Class B,GB9254 CLASS B
Compliance to EN61000-3-2,-3,GB17625.1
HARMONIC CURRENT
Compliance to EN61000-4-2, 3, 4, 5, 6, 8,11, ENV50204, EN55024, EN61000-6-1, heavy industry level, criteria A
EMS IMMUNITY
MTBF
DIMENSION
PACKING
433.3Khrs min. MIL-HDBK-217F (25
199*98*38mm (L*W*H)
0.7Kg; 20pcs/15Kg/0.72CUFT
)
OTHERS
NOTE
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Line regulation is measured from low line to high line at rated load.
5. Load regulation is measured from 0% to 100% rated load.
6. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.
(as available on http://www.meanwell.com)
7. Length of set up time is measured at cold first start. Turning ON/OFF the power supply very quickly may lead to increase of the set up time.
File Name:NES-150-SPEC 2012-03-02
