HMC272MS8 / 272MS8E

v02.0312

GaAs MMIC SMT SINGLE

BALANCED MIXER, 1.7 - 3.0 GHz

Typical Applications

The HMc272Ms8 / HMc272Ms8e is ideal for:

Features

roHs compliant Product

ultra small Package: MsoP8

lo / rF isolation: 32 db

input iP3: +20 dbm

Mixers - single & Double balanceD - sMT

• Up or Down Converter for PCS

• W-CDMA

• 2.4 GHz ISM

• MMDS

Functional Diagram

General Description

The HMc272Ms8 & HMc272Ms8e are general

purpose ultra miniature single balanced mixers in

8 lead plastic surface mount Mini small outline

Packages (MsoP). This passive MMic mixer is

constructed of gaas schottky diodes and a novel

planar transformer balun on the chip. The rF port

is balanced via the MMIC balun while the LO port

is connected directly to the diodes. The consistent

MMIC performance will improve system operation and

assure regulatory compliance.

Electrical Specifications,

= +25° C,

As a Function of IF Frequency

Parameter

Min.

Frequency range, rF & lo

Frequency range, iF

conversion loss

noise Figure (ssb)

lo to rF isolation

lo to iF isolation

iP3 (input)

1 db compression (input)

lo = +10 dbm

IF = 100 MHz

Typ.

2-3

Dc - 0.8

10.5

Max.

Min.

lo = +10 dbm

IF = 400 MHz

Typ.

1.7 - 2.8

Dc - 0.8

Max.

GHz

dbm

units

For price, delivery and to place orders: Hittite Microwave Corporation, 2 Elizabeth Drive, Chelmsford, MA 01824

Phone: 978-250-3343

Fax: 978-250-3373

Order On-line at www.hittite.com

Application Support: Phone: 978-250-3343 or apps@hittite.com
