SN74LS601ADW

Description
SPECIALTY MEMORY CIRCUIT, PDSO20
Categorystorage    storage
File Size884KB,9 Pages
ManufacturerRochester Electronics
Websitehttps://www.rocelec.com/
Download Datasheet Parametric Compare View All

SN74LS601ADW Overview

SPECIALTY MEMORY CIRCUIT, PDSO20

SN74LS601ADW Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
MakerRochester Electronics
Reach Compliance Codeunknown
JESD-30 codeR-PDSO-G20
JESD-609 codee0
length12.8 mm
memory density65536 bit
Memory IC TypeMEMORY CIRCUIT
memory width1
Humidity sensitivity levelNOT SPECIFIED
Number of functions1
Number of terminals20
word count65536 words
character code64000
Operating modeASYNCHRONOUS
Maximum operating temperature70 °C
Minimum operating temperature
organize64KX1
Package body materialPLASTIC/EPOXY
encapsulated codeSOP
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusCOMMERCIAL
Maximum seat height2.65 mm
Maximum supply voltage (Vsup)5.25 V
Minimum supply voltage (Vsup)4.75 V
Nominal supply voltage (Vsup)5 V
surface mountYES
technologyTTL
Temperature levelCOMMERCIAL
Terminal surfaceTIN LEAD
Terminal formGULL WING
Terminal pitch1.27 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
width7.5 mm
