TIGER ELECTRONIC CO.,LTD
FR601 THRU FR607
6.0AMP FAST RECOVERY RECTIFIERS
R－6
φ
0.36( 9.1 )
φ
0.34 ( 8.6 )
VOLTAGE RANGE: 50 to 1000 VOLTS
FEATURES
. Low cost
. Diffused junction
. Low Leakage
. Low forward voltage drop
. High current capability
. Easily cleaned with Freon. Alcohol. Lsopropanol
and similar solvents
. The plastic material carries U/L recognition 94V-O
φ
0.052 ( 1.3 )
φ
0.048 ( 1.2 )
0.36(9.1)
0.34(8.6)
1.0 ( 25.4 )
1.0 ( 25.4 )
MECHANICAL DATA
. Case: JEDEC R－6. molded plastic
. Terminals: Axial leads. Solderable per MIL - STD - 202.
Method 208
inch ( mm )
. Polarity: Color band denotes cathode
. Weight: 0.074 ounce. 2.1 grams
. Mounting position: Any
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
℃
ambient temperature unless otherwise specified.
Single phase half wave 60HZ. resistive or inductive load. For capacitive load current derate
SYMBOL
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
9.5mm Lead Length. TA = 55℃
Peak Forward Surge Current
8.3ms Single half-sine-wave superimposed
on rated load
Maximum Forward Voltage at 6.0A DC
Maximum Reverse Current
TA = 25℃
by 20％
FR607
1000
700
1000
UNITS
V
V
V
A
FR601
50
35
50
FR602
100
70
100
FR603
200
140
200
FR604
400
280
400
6.0
FR605
600
420
600
FR606
800
560
800
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
trr
C
j
T
j
T
STG
150
200
1.3
10.0
200.0
250
55
55 to 125
55 to 150
500
A
V
μA
ns
pF
℃
℃
at Rated DC Blocking Voltage TA = 100℃
Maximum Reverse Recovery Time (Note 1)
Typical Junction Capacitance ( Note 2 )
Operating Junction Temperature Range
Storage Temperature Range
NOTE: 1.Measured with IF=0.5A,IR=1A,Irr=0.25A.
2.Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
3.Thermal Resistance Junction to Ambient.
TIGER ELECTRONIC CO.,LTD
FR601 THRU FR607
FIG. 1 -- TYPICAL FORWARD CHARACTERISTIC
FIG. 2 -- TYPICAL JUNCTION CAPACITANCE
200
INSTANTANEOUS FORWARD CURRENT /
AMPERES
1000
500
100.0
JUNCTION CAPACITANCE(pF)
100
60
40
10.0
20
0
Pulse Width = 300μS
1 % Duly Cycle
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
1.0
0.1
1
10
100
INSTANTANEOUS FORWARD VOLTAGE / VOLTS
REVERSE VOLTAGE / VOLTS
AVERAGE FORWARD RECTIFIED
CURRENT AMPERES
FIG. 3 -- FORWARD CURRENT DERATING CURVE
FIG. 4 -- PEAK FORWARD SURGE CURRENT
Single Phase Half Wave 60HZ
Resistive or Inductive Load
CURRENT AMPERES
6.0
PEAK FORWARD SURGE
200
100
Tj = 125
℃
50
4.0
2.0
8.3 ms Single
Half Sing -
Wave
0
0
25
50
75
100
125
150
175
200
10
1.0
2.0
10
50
100
AMBIENT TEMPERATURE /
℃
NUMBER OF CYCLES AT 60H
Z
FIG. 5 -- TEST CIRCUIT DIAGRAM AND REVERSE RECOVERY TIME CHARACTERISTIC
50Ω
N.1.
10Ω
N.1.
(-)
(+)
25 Vdc
(APPROX)
(-)
1Ω
N.1.
OSCILLOSCOPE
( NOTE )
D.U.T
PULSE GENERATOR
t
rr
0.5A
0
0.25A
( NOTE 2 )
(+)
1.0A
NOTES:
1. RISE TIME = 7n SEC MAX. INPUT IMPEDANCE = 1 MEGOHM. 22
2. RISE TIME = 10n SEC MAX. SOURCE IMPEDANCE = 50 OHM.
SET TIME BASE FOR 15 ns / cm
