CD74HC4538E

Description
Monostable Multivibrator, HC/UH Series, 2-Func, CMOS, PDIP16
Categorylogic    logic
File Size894KB,11 Pages
ManufacturerRochester Electronics
Websitehttps://www.rocelec.com/
Download Datasheet Parametric Compare View All

CD74HC4538E Online Shopping

Suppliers Part Number Price MOQ In stock
CD74HC4538E - - View Buy Now

CD74HC4538E Overview

Monostable Multivibrator, HC/UH Series, 2-Func, CMOS, PDIP16

CD74HC4538E Parametric

Parameter NameAttribute value
MakerRochester Electronics
package instruction,
Reach Compliance Codeunknown
Other featuresRETRIGGERABLE
seriesHC/UH
JESD-30 codeR-PDIP-T16
Logic integrated circuit typeMONOSTABLE MULTIVIBRATOR
Number of data/clock inputs2
Number of functions2
Number of terminals16
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Output polarityCOMPLEMENTARY
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formIN-LINE
Certification statusNot Qualified
Maximum supply voltage (Vsup)6 V
Minimum supply voltage (Vsup)2 V
Nominal supply voltage (Vsup)5 V
surface mountNO
technologyCMOS
Temperature levelMILITARY
Terminal formTHROUGH-HOLE
Terminal locationDUAL
