25F(R) Series

Vishay High Power Products

Standard Recovery Diodes

(Stud Version), 25 A

FEATURES

• High surge current capability

• Stud cathode and stud anode version

• Wide current range

• Types up to 1200 V V

RRM

• RoHS compliant

RoHS

COMPLIANT

TYPICAL APPLICATIONS

DO-203AA (DO-4)

• Battery charges

• Converters

PRODUCT SUMMARY

F(AV)

25 A

• Power supplies

• Machine tool controls

MAJOR RATINGS AND CHARACTERISTICS

PARAMETER

F(AV)

F(RMS)

FSM

RRM

50 Hz

60 Hz

50 Hz

60 Hz

Range

TEST CONDITIONS

VALUES

120

356

373

636

580

100 to 1200

- 65 to 175

UNITS

°C

ELECTRICAL SPECIFICATIONS

VOLTAGE RATINGS

TYPE

NUMBER

VOLTAGE

CODE

RRM

, MAXIMUM

REPETITIVE PEAK

REVERSE VOLTAGE

100

200

400

600

800

1000

1200

RSM

, MAXIMUM

NON-REPETITIVE

PEAK VOLTAGE

150

275

500

725

950

1200

1400

R(BR)

, MINIMUM

AVALANCHE

VOLTAGE

(1)

500

750

950

1150

1350

RRM

MAXIMUM

AT T

= 175 °C

25F(R)

100

120

Note

(1)

Avalanche version only available from V

RRM

400 V to 1200 V

Document Number: 93506

Revision: 29-Sep-08

For technical questions, contact: ind-modules@vishay.com

www.vishay.com

25FR_12 Related Products

	25FR_12	25F40M	25F80M	25FR	25FR100M	25FR10M	25FR120M	25FR20M	25FR60M	25FR80M
Description	25 A, 400 V, SILICON, RECTIFIER DIODE, DO-203AA	25 A, 400 V, SILICON, RECTIFIER DIODE, DO-203AA	25 A, 800 V, SILICON, RECTIFIER DIODE, DO-203AA	25 A, 400 V, SILICON, RECTIFIER DIODE, DO-203AA	25 A, 1000 V, SILICON, RECTIFIER DIODE, DO-203AA	25 A, 100 V, SILICON, RECTIFIER DIODE, DO-203AA	RECTIFIER DIODE	25 A, 200 V, SILICON, RECTIFIER DIODE, DO-203AA	25 A, 600 V, SILICON, RECTIFIER DIODE, DO-203AA	25 A, 800 V, SILICON, RECTIFIER DIODE, DO-203AA
Is it lead-free?	-	Lead free	Lead free	-	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	-	conform to	conform to	-	conform to	conform to	conform to	conform to	conform to	conform to
Parts packaging code	-	DO-4	DO-4	-	DO-4	DO-4	DO-4	DO-4	DO-4	DO-4
package instruction	-	ROHS COMPLIANT, DO-4, 1 PIN	O-MUPM-D1	-	ROHS COMPLIANT, DO-4, 1 PIN	ROHS COMPLIANT, DO-4, 1 PIN	ROHS COMPLIANT, DO-4, 1 PIN	ROHS COMPLIANT, DO-4, 1 PIN	ROHS COMPLIANT, DO-4, 1 PIN	O-MUPM-D1
Contacts	-	1	1	-	1	1	1	1	1	1
Reach Compliance Code	-	compli	compli	-	compli	compli	compli	compli	compli	compli
Other features	-	HPOW	HPOW	-	HPOW	HPOW	HPOW	HPOW	HPOW	HPOW
application	-	GENERAL PURPOSE	GENERAL PURPOSE	-	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Shell connection	-	CATHODE	CATHODE	-	ANODE	ANODE	ANODE	ANODE	ANODE	ANODE
Configuration	-	SINGLE	SINGLE	-	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	-	SILICON	SILICON	-	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	-	RECTIFIER DIODE	RECTIFIER DIODE	-	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	-	1.3 V	1.3 V	-	1.3 V	1.3 V	1.3 V	1.3 V	1.3 V	1.3 V
JEDEC-95 code	-	DO-203AA	DO-203AA	-	DO-203AA	DO-203AA	DO-203AA	DO-203AA	DO-203AA	DO-203AA
JESD-30 code	-	O-MUPM-D1	O-MUPM-D1	-	O-MUPM-D1	O-MUPM-D1	O-MUPM-D1	O-MUPM-D1	O-MUPM-D1	O-MUPM-D1
Maximum non-repetitive peak forward current	-	373 A	373 A	-	373 A	373 A	373 A	373 A	373 A	373 A
Number of components	-	1	1	-	1	1	1	1	1	1
Phase	-	1	1	-	1	1	1	1	1	1
Number of terminals	-	1	1	-	1	1	1	1	1	1
Maximum operating temperature	-	175 °C	175 °C	-	175 °C	175 °C	175 °C	175 °C	175 °C	175 °C
Minimum operating temperature	-	-65 °C	-65 °C	-	-65 °C	-65 °C	-65 °C	-65 °C	-65 °C	-65 °C
Maximum output current	-	25 A	25 A	-	25 A	25 A	25 A	25 A	25 A	25 A
Package body material	-	METAL	METAL	-	METAL	METAL	METAL	METAL	METAL	METAL
Package shape	-	ROUND	ROUND	-	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND
Package form	-	POST/STUD MOUNT	POST/STUD MOUNT	-	POST/STUD MOUNT	POST/STUD MOUNT	POST/STUD MOUNT	POST/STUD MOUNT	POST/STUD MOUNT	POST/STUD MOUNT
Peak Reflow Temperature (Celsius)	-	NOT SPECIFIED	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Certification status	-	Not Qualified	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	-	400 V	800 V	-	1000 V	100 V	1200 V	200 V	600 V	800 V
surface mount	-	NO	NO	-	NO	NO	NO	NO	NO	NO
Terminal form	-	SOLDER LUG	SOLDER LUG	-	SOLDER LUG	SOLDER LUG	SOLDER LUG	SOLDER LUG	SOLDER LUG	SOLDER LUG
Terminal location	-	UPPER	UPPER	-	UPPER	UPPER	UPPER	UPPER	UPPER	UPPER
Maximum time at peak reflow temperature	-	NOT SPECIFIED	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Base Number Matches	-	1	1	-	1	1	1	1	1	1
