TE-3Q3TD50UH+/-5% datasheet, PDF

Datasheet> All Categories > Passive components> inductor> TE-3Q3TD50UH+/-5%

TE-3Q3TD50UH+/-5%: DescriptionGeneral Fixed Inductor, 1 ELEMENT, 50 uH, GENERAL PURPOSE INDUCTOR, RADIAL LEADED; CategoryPassive components inductor; File Size81KB，5 Pages; ManufacturerVishay; Websitehttp://www.vishay.com

Download Datasheet Parametric View All

TE-3Q3TD50UH+/-5% Overview

General Fixed Inductor, 1 ELEMENT, 50 uH, GENERAL PURPOSE INDUCTOR, RADIAL LEADED

TE-3Q3TD50UH+/-5% Parametric

Parameter Name	Attribute value
Maker	Vishay
Reach Compliance Code	unknown
ECCN code	EAR99
Nominal inductance(L)	50 µH
Inductor Applications	FILTER CHOKE
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e3
Number of functions	1
Number of terminals	2
Maximum operating temperature	55 °C
Minimum operating temperature
Shape/Size Description	CYLINDRICAL PACKAGE
shield	NO
surface mount	NO
Terminal surface	TIN
Terminal location	RADIAL
Terminal shape	WIRE
Tolerance	5%

Preview

Download Datasheet

View All

TE and TD

Vishay Dale

Filter Inductors

Toroid

FEATURES

•

Choice of encapsulated (TE) or dipped (TD) styles.

•

TD style combines low cost with excellent performance

in commercial applications.

•

High Q and wide selection of Q versus frequency ranges in one

small package. Large number of standard inductance values.

STANDARD ELECTRICAL SPECIFICATIONS

(Applies to Core Only)

MODEL

TE-3

TD-3

TE-4

TD-4

TE-5

TD-5

CODE

TL*

TEMPERATURE

COEFFICIENT

0.1%

+ 40 to + 110PPM/°C

+ 85 to + 185PPM/°C

0.25%

50PPM/°C (Typical)

0.25%

TEMPERATURE

RANGE

- 55°C to + 125°C

0°C to + 55°C

- 55°C to + 25°C

+ 25°C to + 85°C

- 65°C to + 125°C

- 55°C to + 85°C

AVAILABILITY

*Inverse of typical Temperature Coefficient of polystyrene capacitor.

INDUCTANCE RANGES

CODE

TE-3

TD-3

50µH to 15mH

500µH to 1H

1mH to 4H

TE-4

TD-4

150µH to 20mH

1mH to 2H

2mH to 5H

TE-5

TD-5

1mH to 100mH

5mH to 2H

10mH to 5H

ELECTRICAL SPECIFICATIONS

Tolerance:

TE-3, TD-3 =

1% > 2mH,

2% 154µH to 2mH,

5% < 150µH.

TE-4, TD-4 =

1% > 2mH,

2% < 2mH.

TE-5, TD-5 =

1% > 2mH,

2% < 2mH.

Insulation Resistance:

1000 Megohm minimum.

Dielectric Strength:

1000V minimum (TE).

500V minimum (TD).

DIMENSIONS

in inches [millimeters]

A Dia.

Max.

.375

.125

[9.53

3.18]

MECHANICAL SPECIFICATIONS

Terminal Strength:

2 pounds pull test (TE).

Vibration:

Per MIL-T-27 (TE).

A Dia.

Max.

Min.

C Min.

Max.

Dia.

Shock:

Per MIL-T-27 (TE).

Weight:

B Max.

F Min.

Dia.

MODEL

TE-3

TD-3

TE-4

TD-4

TE-5

TD-5

0 .685

[17.40]

0.685

[17.40]

1.06

[26.92]

1.06

[26.92]

1.32

[33.53]

1.32

[33.53]

0.385

[9.78]

0.320

[8.13]

0.500

[12.70]

1.0

[25.40]

3.0

[76.20]

1.0

[25.40]

0.025

[0.635]

—

0.032

[0.813]

—

0.500

[12.70]

—

0.900

[22.86]

—

0.093

[2.36]

0.125

[3.18]

0.250

[6.35]

—

TE-3 = 5.1 grams, TD-3 = 4.9 grams typical.

TE-4 = 20 grams, TD-4 = 17 grams typical.

TE-5 = 53 grams, TD-5 = 52 grams typical.

MATERIAL SPECIFICATIONS

Coating:

Vinyl (TD), non-flammable, abrasion and

moisture resistant. Resists most cleaning agents.

(Consult factory for chemicals which may be used.)

Standard Terminals:

Tinned copper (TE).

Stranded, tinned copper, Teflon insulated (TD).

Encapsulant:

Epoxy (TE).

Gauge:

TE-3 = 22 AWG, TD-3 = 26 AWG.

TE-4 = 20 AWG, TD-4 = 24 AWG.

TE-5 = 20 AWG, TD-5 = 24 AWG.

0.120 0.450

[3.05] [11.43]

0.220

[5.59]

—

4.0

0.437

[11.10] [101.60]

0.725

[18.42]

1.0

[25.40]

0.032

1.0

[0.813] [25.40]

—

0.144 0.500

[3.66] [12.70]

0.220

[5.59]

—

6.0

0.688

[17.48] [152.40]

www.vishay.com

For technical questions, contact Magnetics@vishay.com

Document Number 34078

Revision 09-Apr-02
