MM3Z6V8B

Description
6.8 V, 0.2 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE
Categorysemiconductor    Discrete semiconductor
File Size666KB,4 Pages
ManufacturerHTSEMI( Jin Yu Semiconductor )
Websitehttp://www.htsemi.com
Download Datasheet Parametric View All

MM3Z6V8B Online Shopping

Suppliers Part Number Price MOQ In stock
MM3Z6V8B - - View Buy Now

MM3Z6V8B Overview

6.8 V, 0.2 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE

MM3Z6V8B Parametric

Parameter NameAttribute value
Number of terminals2
Number of components1
Rated working voltage6.8 V
Processing package descriptionLEAD FREE, SC-90, 2 PIN
Lead-freeYes
EU RoHS regulationsYes
stateACTIVE
packaging shapeRECTANGULAR
Package SizeSMALL OUTLINE
surface mountYes
Terminal formFLAT
terminal coatingMATTE TIN
Terminal locationDUAL
Packaging MaterialsPLASTIC/EPOXY
CraftsmanshipZENER
structureSINGLE
Diode component materialsSILICON
Maximum power consumption limit0.2000 W
polarityUNIDIRECTIONAL
Diode typeVOLTAGE REGULATOR DIODE
Working test current5 mA
Maximum total reference voltage2 %
MM3Z2V2B~MM3Z39B
Silicon Planar Zener Diodes
Features
• Total power dissipation : max. 300 mW
Small plastic package suitable for
surface mounted design
• High reliability
PINNING
PIN
1
2
1
DESCRIPTION
Cathode
Anode
2
Description
Silicon planar Zener diode in a small plastic
SMD SOD-323 package
Top View
Simplified outline SOD-323 and symbol
Absolute Maximum Ratings (T
a
= 25
O
C)
Parameter
Power Dissipation
Junction Temperature
Storage Temperature Range
Symbol
P
tot
T
j
T
stg
Value
300
150
- 55 to + 150
Unit
mW
O
C
C
O
Characteristics at T
a
= 25
O
C
Parameter
Thermal Resistance Junction to Ambient Air
Forward Voltage
at I
F
= 10 mA
Symbol
R
thA
V
F
Max.
417
0.9
Unit
O
C/W
V
1
JinYu
semiconductor
www.htsemi.com
D½½½:2011/05
