DTA143EE/DTA143EUA/
DTA143ECA/DTA143EKA/DTA143ESA
DIGITAL TRANSISTOR (PNP)
FEATURES
1. Built-in bias resistors enable the c onfiguration of an inverter circuit
without connecting external input resistors (see equivalent circuit).
2. The bias resistors cons ist of thin-film resistors with complete isolation
to allow
positive
biasing of the input. They also have the advantage of
almost completely eliminating parasitic effects.
3. Only the on/off conditions need to be set for operation, making
device design easy.
PIN CONNENCTIONS AND MARKING
DTA143EE
DTA143EUA
DTC114EUA
SOT-323
SOT-523
Addreviated symbol: 13
Addreviated symbol: 13
DTA143EKA
DTA143ECA
SOT-23-3L
SOT-23
Addreviated symbol: 13
Addreviated symbol: 13
DTA143ESA
TO-92S
１
JinYu
semiconductor
www.htsemi.com
Ｄ½½½：２０１１／０５
DTA143EE/DTA143EUA/
DTA143ECA/DTA143EKA/DTA143ESA
Absolute maximum ratings(Ta=25
℃
)
Parameter
Supply voltage
Input voltage
Output current
Power dissipation
Junction
temperature
Storage temperature
Parameter
Input voltage
Output voltage
Input current
Output current
DC current gain
Input resistance
Resistance ratio
Transition frequency
Symbol
V
CC
V
IN
I
O
I
C(MAX)
Pd
T
j
Tstg
Symbol
V
I(off)
V
I(on)
V
O(on)
I
I
I
O(off)
G
I
R
1
R
2
/R
1
f
T
30
3.29
0.8
-3
Min.
Limits (DTA143E□ )
E
UA
KA
CA
SA
Unit
V
V
mA
-50
-30~10
-100
-100
150
200
150
-55~150
Typ
Max.
-0.5
-0.3
-1.8
-0.5
4.7
1
250
6.11
1.2
MHz
Unit
V
V
mA
µA
KΩ
Conditions
V
CC
=-5V ,I
O
=-100µA
V
O
=-0.3V ,I
O
=-20
mA
I
O
/I
I
=-10mA/-0.5mA
V
I
=-5V
V
CC
=-50V ,V
I
=0
V
O
=-5V ,I
O
=-10mA
300
mW
℃
℃
Electrical characteristics (Ta=25
℃
)
V
O
=-10V ,I
O
=5mA,f=100MHz
Typical Characteristics
２
JinYu
semiconductor
www.htsemi.com
Ｄ½½½：２０１１／０５
