BBRF750-2: DescriptionRESISTOR, TEMPERATURE DEPENDENT, PTC RESETTABLE FUSE, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT; CategoryPassive components The resistor; File Size109KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

BBRF750-2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BBRF750-2	-	-	View	Buy Now

BBRF750-2 Overview

RESISTOR, TEMPERATURE DEPENDENT, PTC RESETTABLE FUSE, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT

BBRF750-2 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	TE Connectivity
package instruction	RADIAL LEADED, ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	RESISTANCE RANGE(MIN-MAX): 0.4-0.75
Manufacturer's serial number	BBRF
Installation features	THROUGH HOLE MOUNT
Number of terminals	2
Maximum operating temperature	85 °C
Package shape	DISK PACKAGE
method of packing	TR
Rated (AC) voltage (URac)	99 V
Rated power dissipation(P)	1.7 W
Resistor type	PTC RESETTABLE FUSE
surface mount	NO
Terminal surface	NOT SPECIFIED
Terminal location	RADIAL
Terminal shape	WIRE
Thermistor Applications	TEMPERATURE SENSING

BBRF750-2 Preview

C orporate Hom e

|

Electronic Components

|

Se gm e nts

|

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

>

Products

>

By Type

>

PolySwitch Resettable Devices

>

Product Feature Selector

> Product Details

BBRF750-2 Product Details

PolySwitch Resettable Devices

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

BBRF750-2

T E I nternal N umber: A 2 6 9 3 9 - 0 0 0

Product Highlights:

l

Radial Application

l

Family Name = BBRF

l

Radial C onstruction, Through Hole C onstruction

l

IH (Room Temperature) = .75 Amps.

l

IT (Room Temperature) = 1.80 Amps.

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

l

BBRF750

(PDF, English)

Catalog Pages/Data Sheets:

l

None Available

Product Specifications:

l

None Available

Application Specifications:

l

None Available

Instruction Sheets:

l

None Available

CAD Files:

l

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

l

UL Recognized = File No. E74889

l

C SA File No. = 78165C

Electrical Characteristics:

l

IH (Room Temperature) (Amps.)

= 0.75

l

IT (Room Temperature) (Amps.)

= 1.80

l

Vmax Operating (V)

= 99

l

Rmin (?)

= 0.40

l

Rmax (?)

= 0.750

l

R1 Max [Post Trip] (?)

= 1.20

l

Power Dissipation (Typical) (W) = 1.70

Termination Related Features:

l

C onstruction = Radial, Through Hole

Body Related Features:

l

Lead Type = Standard Kinked Lead

Contact Related Features:

l

Family Name = BBRF

Configuration Related Features:

l

C oating = C oated

Industry Standards:

l

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

l

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

l

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

l

Operating Temperature (Max.) (?C )

= 85

Operation/Application:

l

Application = Radial

Packaging Related Features:

l

Packaging Method = Tape & Reel

Other:

l

Brand = Raychem

Additional Information:

l

Product Line Information

BBRF750-2 Related Products

	BBRF750-2	A26939-000
Description	RESISTOR, TEMPERATURE DEPENDENT, PTC RESETTABLE FUSE, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT	RESISTOR, TEMPERATURE DEPENDENT, PTC RESETTABLE FUSE, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT
Is it lead-free?	Lead free	Lead free
Is it Rohs certified?	conform to	conform to
Maker	TE Connectivity	TE Connectivity
Reach Compliance Code	compliant	unknown
ECCN code	EAR99	EAR99
Other features	RESISTANCE RANGE(MIN-MAX): 0.4-0.75	RESISTANCE RANGE(MIN-MAX): 0.4-0.75
Manufacturer's serial number	BBRF	BBRF
Installation features	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT
Number of terminals	2	2
Maximum operating temperature	85 °C	85 °C
Package shape	DISK PACKAGE	DISK PACKAGE
method of packing	TR	TR
Rated (AC) voltage (URac)	99 V	99 V
Rated power dissipation(P)	1.7 W	1.7 W
Resistor type	PTC RESETTABLE FUSE	PTC RESETTABLE FUSE
surface mount	NO	NO
Terminal surface	NOT SPECIFIED	NOT SPECIFIED
Terminal location	RADIAL	RADIAL
Terminal shape	WIRE	WIRE
Thermistor Applications	TEMPERATURE SENSING	TEMPERATURE SENSING
