MULTI-LAYER FERRITE
CHIP BEAD
R8M0603 SERIES
• RoHS Compliant Product
• Operating Temperature: -40°C to +85°C
• Ordering code R8M0603-XXX (Value)
• Package: Tape and Reel is the standard
ELECTRICAL SPECIFICATION @ 25°C
PART NO
Impedance
@100MHz
(W)±25%
11
19
30
40
60
80
120
220
300
450
600
750
1000
1500
2200
2700
R8M0603-
110
190
300
400
600
800
121
221
301
451
601
751
102
152
222
272
DCR
Max
(W)
0.05
0.08
0.10
0.10
0.10
0.15
0.25
0.30
0.40
0.50
0.50
0.70
0.70
1.00
1.20
1.30
RATED
I
DC
(mA)
500
500
400
400
300
300
300
200
200
200
200
200
200
50
50
50
Mechanical
Schematic
A
0.063±0.006
1,60±0,15
B
0.032±0.006
0,80±0,15
C
0.032±0.008
0,80±0,20
D
0.020±0.008
0,50±0,20
E Typ
0.032
0,80
F Typ
0.120
3,05
G Typ
0.024
0,60
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ± 0.015 .XXX : ±0.004
mm: X,X : ± 0,38 X,XX : ±0,10
Product performance is limited to specified parameter. Data is subject to change without prior notice.
R8M0603-XXX
0620JW
2463 208th, Ste. 205
Torrance, CA 90501
Phone: (310)533-1455
Fax:
(310)533-1853
http://www.mpsind.com
Email: sales@mpsind.com
