Product specification
N-Channel Power Mosfet
FEATURES
BL03N10C-6L
Pb
Lead-free
Special process technology for high
ESD capability
Good stability and uniformity with high E
AS
Excellent package for good heat dissipation
Electrostatic Sensitive Devices.
APPLICATIONS
Power switching application
Hard switching and high frequency circuits
Uninterruptible power supply
SOT-23-6L
ORDERING INFORMATION
Type No.
BL03N10C
□
-6L
Marking
03N10
Package Code
SOT-23-6L
□:
none is for Lead Free package;
“G” is for Halogen Free package.
MAXIMUM RATING
@ Ta=25℃ unless otherwise specified
Symbol
V
DSS
V
GSS
I
D
I
DM
P
D
R
θJA
T
J
Tstg
MTM0102A
Parameter
Drain-Source voltage
Gate -Source voltage
Continuous
Drain Current
Pulsed Drain
Current
Power Dissipation
Thermal resistance,Junction-to-Ambient
Junction Temperature
Storage Temperature
Value
100
±20
3
20
0.2
250
+150
-55 to +150
Units
V
V
A
A
W
℃/W
℃
℃
www.gmesemi.com
1
Product specification
N-Channel Power Mosfet
BL03N10C-6L
ELECTRICAL CHARACTERISTICS
@ Ta=25℃ unless otherwise specified
Parameter
STATIC CHARACTERISTICS
Drain-Source Breakdown Voltage
Zero Gate Voltage Drain Current
Gate-body Leakage
Gate Threshold Voltage
Static drain-Source on-resistance
Forward Transconductance
Drain-Source diode forward voltage
DYNAMIC CHARACTERISTICS
Input capacitance
Output capacitance
Reverse transfer capacitance
SWITCHING CHARACTERISTICS
Turn-On Delay Time
Rise Time
Turn-Off Delay Time
Fall Time
Total Gate Charge
Gate-Source Charge
Gate-Drain Charge
t
D(ON)
tr
t
D(OFF)
tf
Qg
Qgs
Qgd
V
DS
= 30V
I
D
= 3A
V
GS
= 10V,
V
GS
= 10V ,V
DS
= 30V,
I
D
= 2A, R
L
= 15Ω
R
G
= 2.5Ω
-
-
-
-
-
-
-
11
7.4
35
9.1
15.5
3.2
4.7
-
-
-
-
-
-
-
ns
ns
ns
ns
nC
nC
nC
C
ISS
C
OSS
C
RSS
V
DS
=25V,V
GS
=0V,f=1.0MHz
-
-
-
690
120
90
-
-
-
pF
BV
DSS
I
DSS
I
GSS
V
GS(th)
R
DS(ON)
gFS
V
SD
V
GS
=0V,I
D
=250μA
V
DS
=100V, V
GS
=0V
V
DS
=0V, V
GS
=±20V
V
DS
=V
GS
, I
D
=250μA
V
GS
=10V,I
D
=3A
V
DS
=5V, I
D
=2.9A
V
GS
=0V,I
s
=3A
100
-
-
1.0
-
-
-
-
-
-
-
-
-
-
-
1
±100
2.5
250
5
1.2
V
μA
nA
V
mΩ
S
V
Symbol
Test conditions
MIN
TYP
MAX
UNIT
MTM0102A
www.gmesemi.com
2
