REVISION W
DO NOT
SCALE FROM
THIS PRINT
.1332 3.384 REF
02
.2450 6.223
REF
01
.0200 0.508 REF
C2
BSH-XXX-01-X-D-XX-XX
No OF POSITIONS
-030, -050, -060, -090,
**-120, **-150, *-180
(PER ROW)
**= SEE NOTE 10
.2850 7.239
REF
LEAD STYLE
-01: .1280 [3.25]
OPTION
-TR: TAPE & REEL
(120 POSITION MAX)
OPTION
-A: ALIGNMENT PINS
(USE BSH-XXX-01-D-A)
-LC: LOCKING CLIPS
(USE LC-08-TM-01)
ROW SPECIFICATION
-D: DOUBLE (USE BSH-XXX-01-D)
{(No OF POSITIONS x .01969[.50])
+ .2468[6.3]}
(No OF POSITIONS -1) x .01969[.50]
.1500 3.810 REF
BSH-XXX-01-D
.0197±.003 0.500±0.08 (TYP)
.042 1.07 REF
PLATING SPECIFICATION
-F: FLASH SELECTIVE GOLD WITH MATTE TIN TAILS
(SEE NOTES 7, 9 & 12)
-L: LIGHT SELECTIVE GOLD WITH MATTE TIN TAILS
(SEE NOTE 9 & 12)
-H: HEAVY GOLD WITH FLASH GOLD TAILS
(SEE NOTE 9 &12)
-C: ELECTRO-POLISHED SELECTIVE
(SEE NOTE 9 &12)
* = NOT RELEASED FOR PRODUCTION
C-126-21-X
(SEE NOTE 12)
C1
SEE NOTE 11
.0550 1.397
"A"
+.0030
.1200 3.048 REF
C3
SEE TABLE 1
.1280
- .0010
3.251
- 0.025
(SEE NOTE 6)
+0.076
"A"
.0100 0.254 REF
.0060 0.152 REF
LC-08-TM-01
.070 1.765 REF
.2950 7.493 REF
BSH-XXX-01-D-A
.0980 2.489 REF
.0425 1.080 REF
-LC: LOCKING CLIP OPTION SHOWN
SEE NOTE 11
.0375 0.953
REF
NOTES:
SECTION "A"-"A"
SCALE 5 : 1
R
.0375 0.953 REF
.0350 0.889 REF
(No OF POSITIONS x .01969 [.5001])
+ .2018 [5.126] REF
-A: ALIGNMENT PIN OPTION SHOWN
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
.XX: .01 [.25]
2
.XXX: .005 [.13]
.XXXX: .0020 [.050]
MATERIAL:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. NOTE DELETED.
3. BURR ALLOWANCE: .0015 [.038] MAX.
4. MINIMUM PUSHOUT FORCE: 6 OZ.
5. MAXIMUM ALLOWABLE BOW: .002 [.051] INCH/INCH AFTER ASSEMBLY.
6. MAX VARIENCE OF .002 [.051]
7. -L PLATING CAN BE SUBSTITUDED FOR -F PLATING.
8. ASP-65067-01 IS A BSH-050-01-L-D-A. WITH OR WITHOUT -TR.
9. MAY SUBSTITUTE C-126-01-X FOR C-126-21-X.
10. FOR NEWAPPLICATIONS REQUIRING THESE POSITIONS, PLEASE
CONTACT SAMTEC INTERCONNECT PROCESSING GROUP.
11. SIDE WALLS MAY BE RIBBED TO AVOID BOW
12. -120 & -150 POSITION PARTS USE C-269-01-X. DO NOT SUB C-126-XX-X.
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
DECIMALS
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DO NOT SCALE DRAWING
SHEET SCALE: 1:0.666667
DESCRIPTION:
FLAMMABILITY RATING: UL 94V-O
INSULATOR: BLACK LCP
CONTACT: PHOS BRONZE
F:\DWG\MISC\MKTG\BSH-XXX-01-X-D-XX-XX-MKT.SLDDRW
.5mm DOUBLE ROW SOCKET ASSEMBLY
DWG. NO.
BY:
DEAN P
BSH-XXX-01-X-D-XX-XX
06/08/1999
SHEET
1
OF
2
REVISION W
POSITION 1
TAPE AND REEL PACKAGING VIEW
"B"
2.205 55.999
REF
"B"
.630 16.00
W
USER DIRECTION OF UN-REELING
POCKET NOT DETAILED
SECTION "B"-"B"
SCALE 1 : 1
[PARTS TO HAVE POSITION #1 LOADED
IN SAME DIRECTION AS ARROW]
TUBE PACKAGING VIEW
TUBE: PT-1-24-02-78
PLUG: TP-09
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
.5mm DOUBLE ROW SOCKET ASSEMBLY
BSH-XXX-01-X-D-XX-XX
06/08/1999
SHEET
2
OF
2
F:\DWG\MISC\MKTG\BSH-XXX-01-X-D-XX-XX-MKT.SLDDRW
BY:
DEAN P
