ENCAPSULATION
MOLDED CHIP INDUCTOR
R7X1210M SERIES
• RoHS Compliant Product
• Ordering Code: R7X1210M-XXX( J, K Tolerance)
• Inductance Tolerance: J = ±5%, K = ±10%
(K is standard tolerance)
• Package: Tape and Reel is the standard, 2000 pcs per reel
• Operating Temperature: -40°C to +85°C
ELECTRICAL SPECIFICATION @ 25°C
Part Number
L
(µH)
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.00
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
20
20
20
20
20
Mechanical
I
DC
Max
(mA)
450
450
450
450
450
450
450
450
450
450
450
400
390
370
350
320
290
260
250
220
200
200
180
170
150
140
130
120
110
80
70
65
60
55
50
45
40
70
65
60
Q
Min
R7X1210M-
R12
R15
R18
R22
R27
R33
R39
R47
R56
R68
R82
1R0
1R2
1R5
1R8
2R2
2R7
3R3
3R9
4R7
5R6
6R8
8R2
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
L.Q Test
Freq.
(MHz)
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.79
0.79
0.79
0.79
0.79
SRF
Min
(MHz)
500
450
400
350
320
300
250
220
180
160
140
120
100
85
80
75
70
60
55
50
47
43
40
36
33
28
25
23
18
17
16
15
13
12
11
10
10
8
7
7
R
DC
Max
(
W
)
0.22
0.25
0.28
0.32
0.36
0.40
0.45
0.50
0.55
0.60
0.65
0.70
0.75
0.85
0.90
1.00
1.10
1.20
1.30
1.50
1.60
1.80
2.00
2.10
2.50
2.80
3.30
3.70
5.00
2.60
6.40
7.00
8.00
9.00
10.0
11.0
12.0
15.0
17.0
21.0
A
0.126±0.012
3,20±0,30
B
0.10
2,5
C
0.09
2,2
D
0.12
2,9
E
0.030
0,75
F
0.040
1,00
H
0.056
1,40
I
0.036
0,90
J
0.080
2,00
Schematic
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ± 0.008 .XXX : ±0.004
mm: X,X : ± 0,20 X,XX : ±0,10
R7X1210M-XXX
0606JW
