P170703-270: DescriptionSHIELDED SMD POWER INDUCTOR; File Size111KB，1 Pages; ManufacturerMPS Industries; Websitehttp://www.mpsind.com/index.html

Download Datasheet View All

P170703-270 Overview

SHIELDED SMD POWER INDUCTOR

Preview

Download Datasheet

View All

SHIELDED SMD POWER

INDUCTOR

P170703 SERIES

• RoHS Compliant Product

• Inductance measured : < 100µH : 100KHz, 0.25V

RMS

• Inductance measured :

100µH : 1KHz, 0.25V

RMS

• Inductance Tolerance: K=±10%, L=15±%, M=±20%

Add suffix letter for tolerance after the part number

• I

RATED

: Max 10% inductance drop and

∆T=40°C

Temp Rise

• Operating Temperature: -40°C to +85°C

ELECTRICAL SPECIFICATION @ 25°C

PART NO

±20%

(µH)

1.0

1.5

2.2

3.3

3.9

4.7

5.6

6.8

100

120

150

180

220

270

330

390

470

560

680

820

1000

Mechanical

DCR

Max

(W)

0.016

0.023

0.027

0.031

0.041

0.048

0.056

0.062

0.072

0.098

0.13

0.14

0.19

0.21

0.24

0.32

0.36

0.47

0.52

0.69

0.79

0.89

1.27

1.45

1.65

2.31

2.62

2.94

4.18

4.67

5.73

6.54

9.44

RATED

(A)

7.97

5.5

4.5

4.0

3.8

3.5

3.0

2.5

1.68

1.52

1.33

1.20

1.07

0.96

0.91

0.77

0.76

0.68

0.61

0.57

0.50

0.49

0.43

0.39

0.35

0.32

0.28

0.26

0.24

0.22

0.19

0.18

0.16

P170703-

1R0

1R5

2R2

3R3

3R9

4R7

5R6

6R8

100

120

150

180

220

270

330

390

470

560

680

820

101

121

151

181

221

271

331

391

471

561

681

821

102

Schematic

Dimensions

Unless otherwise specified, all tolerances are:

inch: .XX : ± 0.015 .XXX : ±0.010

mm: X,X : ± 0,38 X,XX : ±0,25

P170703-XX

0602JW

Product performance is limited to specified parameter. Data is subject to change without prior notice.

13200 Estrella Ave., Bldg. B

Gardena, CA 90248

Tel: (310) 325-1043

Fax: (310) 325-1044

www.mpsind.com
