SHIELDED SMD POWER
INDUCTOR
P171207 SERIES
• RoHS Compliant Product
• Inductance measured : < 100µH : 100KHz, 0.25V
RMS
• Inductance measured :
>
100µH : 1KHz, 0.25V
RMS
• Inductance Tolerance: K=±10%, L=15±%, M=±20%
Add suffix letter for tolerance after the part number
• I
RATED
: Max 10% inductance drop and
∆T=40°C
Temp Rise
• Operating Temperature: -40°C to +85°C
ELECTRICAL SPECIFICATION @ 25°C
PART NO
L
±20%
(µH)
1.0
1.2
2.4
3.5
4.7
6.1
7.6
10
12
15
18
22
27
33
39
47
100
470
560
680
820
1000
DCR
Max
(W)
0.007
0.007
0.012
0.014
0.016
0.018
0.020
0.022
0.025
0.027
0.040
0.044
0.046
0.065
0.073
0.100
0.130
0.740
1.070
1.460
1.640
1.820
RATED
(A)
10.5
9.80
8.00
7.50
6.80
6.60
5.90
5.40
4.90
4.50
3.90
3.60
3.40
3.00
2.75
2.50
1.60
0.79
0.73
0.67
0.60
0.55
0.49
[12.50]
max.
Mechanical
P171207-
1R0
1R2
2R4
3R5
4R7
6R1
7R6
100
120
150
180
220
270
330
390
470
101
471
561
681
821
102
I
DC
0.49
[12.50]
max.
0.083
[2.10]
0.319
[8.10]
0.201
[5.10]
Suggested Pad Layout
0.315
[8.00]
max.
Schematic
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ± 0.015 .XXX : ±0.004
mm: X,X : ± 0,38 X,XX : ±0,10
Product performance is limited to specified parameter. Data is subject to change without prior notice.
P171207-XX
