SMD POWER INDUCTOR
P10DR105 SERIES
• RoHS Compliant Product
• Inductance measured : < 100µH : 100KHz, 0.25V
RMS
• Inductance measured :
>
100µH : 1KHz, 0.25V
RMS
• Inductance Tolerance: J=±5%, K=±10%, L=15±%, M=±20%
Add suffix letter for tolerance after the part number
• I
RATED
: Max 10% inductance drop and
∆T=40°C
Temp Rise
• Operating Temperature: -40°C to +85°C
ELECTRICAL SPECIFICATION @ 25°C
PART NO
Mechanical
P10DR105-
1R2
1R5
2R2
3R3
3R9
4R7
5R6
6R8
8R2
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
271
331
391
471
561
681
821
102
L
±20%
(µH)
1.2
1.5
2.2
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
DCR
Max
(mW)
8
10
13
15
18
20
25
30
50
60
70
80
90
100
110
120
140
170
190
220
250
350
400
470
630
730
970
1150
1300
1480
1900
2250
2550
2700
RATED
I
DC
(A)
10.50
9.50
8.50
7.50
6.80
6.00
5.00
4.20
3.50
2.60
2.45
2.27
2.15
1.95
1.76
1.50
1.37
1.28
1.17
1.11
1.00
0.97
0.89
0.78
0.72
0.66
0.57
0.52
0.48
0.42
0.33
0.28
0.24
0.20
±10%
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Schematic
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ± 0.015 .XXX : ±0.004
mm: X,X : ± 0,38 X,XX : ±0,10
P10DR105-XX
0603JW
Product performance is limited to specified parameter. Data is subject to change without prior notice.
