SHIELDED RADIAL IN-
DUCTOR
P11RS2875 SERIES
• RoHS Compliant Product
• Ferrite shielded inductor
• Lp tested at 1KHz, 1.0V
RMS
• Inductance Tolerance: M = ±20%
• I
DC
: 10% inductance drop typical from initial value
• I
RMS
:
∆T ≤
40°C Temp Rise at rated current
• Operating Temperature: -40°C to +85°C
ELECTRICAL SPECIFICATION @ 25°C
PART NO
Mechanical
P11RS2875-
100M
120M
150M
180M
220M
270M
330M
390M
470M
560M
680M
820M
101M
121M
151M
181M
221M
271M
331M
391M
471M
561M
681M
821M
102M
122M
152M
182M
222M
272M
332M
392M
472M
562M
682M
822M
103M
Lp
±20%
(µH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
DCR
Max
(W)
0.047
0.055
0.068
0.083
0.097
0.130
0.140
0.170
0.210
0.230
0.280
0.400
0.450
0.50
0.63
0.68
0.91
1.00
1.20
1.30
1.70
2.10
2.30
3.10
3.90
4.30
5.80
7.10
7.9
11.0
12.0
16.1
18.1
25.4
28.8
41.8
46.8
RATED
I
DC
(A)
3.60
3.20
2.96
2.72
2.48
2.08
2.00
1.68
1.60
1.44
1.36
1.28
1.12
1.04
0.96
0.88
0.75
0.70
0.65
0.56
0.53
0.42
0.41
0.38
0.35
0.33
0.27
0.26
0.24
0.20
0.18
0.17
0.16
0.14
0.13
0.12
0.11
RATED
I
RMS
(A)
2.95
2.70
2.25
2.10
2.00
1.75
1.70
1.50
1.32
1.11
1.00
0.92
0.84
0.80
0.72
0.70
0.53
0.51
0.44
0.42
0.37
0.33
0.31
0.28
0.24
0.22
0.18
0.17
0.16
0.14
0.13
0.12
0.11
0.10
0.09
0.08
0.07
DIM
A
B
C
E
F
8,3 Max
7,5 Max
5,0 ± 1,0 min
5,0 ± 0,5
0,60
mm
Schematic
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ± 0.010 .XXX : ±0.003
mm: X,X : ± 0,254 X,XX : ±0,076
P11RS2875-XXX
0709JW
Product performance is limited to specified parameter. Data is subject to change without prior notice.
