TOROIDAL INDUCTOR
P11TJ3 SERIES
• RoHS Compliant Product
• Operating Temp: -55°C to +105°C
• Inductance test @ 10KHz, 0.1V
RMS
• I
DC
: 10% inductance drop typ from initial value at rated current
• I
RMS
:
∆30°C
temperature rise max at rated current
• Add -V for Vertical Mount, -H for Horizontal Mount after
part number
ELECTRICAL SPECIFICATION @ 25°C
P11TJ3-
1R2-5.5
1R5-4.7
2R2-4.1
2R7-3.7
3R3-3.3
3R9-3
4R7-2.8
5R6-2.5
6R8-2.4
8R2-2.1
100-2
120-1.7
150-1.6
180-1.4
220-1.3
270-1.1
330-1
390-1
470-R9
PART
NUMBER
L (µH)
±15%
10KHz 0.1VRMS
1.2
1.5
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
I
DC
(A)
5.50
4.71
4.13
3.67
3.30
3.00
2.75
2.54
2.36
2.06
1.94
1.74
1.57
1.43
1.27
1.14
1.03
0.97
0.87
I
RMS
(A)
10
9.5
9.0
8.4
8.2
7.9
7.5
7.3
7.1
6.6
6.5
6.1
5.9
5.6
4.6
4.4
4.3
3.7
3.5
R
DC
MAX
(
W
)
0.006
0.006
0.007
0.008
0.008
0.009
0.010
0.011
0.011
0.013
0.015
0.016
0.016
0.017
0.024
0.026
0.029
0.038
0.043
DIM A
INCH
NOM
0.032
0.003
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.029
0.029
0.029
0.025
0.025
Mechanical
Schematic
13200 Estrella Ave., Bldg. B
Gardena, CA 90248
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ± 0.008
.XXX : ±0.004
mm: X,X : ± 0,20 X,XX : ±0,10
P11TJ3-XXX
Product performance is limited to specified parameter. Data is subject to change without prior notice.
0547JW
Tel: (310) 325-1043
Fax: (310) 325-1044
www.mpsind.com
sales@mpsind.com
TOROIDAL INDUCTOR
P11TJ3 SERIES
• RoHS Compliant Product
• Operating Temp: -55°C to +105°C
• Inductance test @ 10KHz, 0.1V
RMS
• I
DC
: 10% inductance drop typ from initial value at rated current
• I
RMS
:
∆30°C
temperature rise max at rated current
• Add -V for Vertical Mount, -H for Horizontal Mount after
part number
ELECTRICAL SPECIFICATION @ 25°C
P11TJ3-
560-R8
680-R7
820-R66
101-R6
121-R55
151-R5
181-R45
221-R4
271-R37
331-R33
391-R3
471-R28
561-R25
681-R23
821-R21
102-R19
122-R17
152-R15
PART
NUMBER
L (µH)
±15%
10KHz 0.1VRMS
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
I
DC
(A)
0.80
0.73
0.66
0.60
0.55
0.49
0.45
0.40
0.37
0.33
0.30
0.28
0.25
0.23
0.21
0.19
0.17
0.15
I
RMS
(A)
3.1
3.0
2.6
2.4
2.3
1.9
1.8
1.5
1.4
1.2
1.1
1.0
0.9
0.8
0.7
0.7
0.6
0.5
R
DC
MAX
(
W
)
0.057
0.063
0.087
0.097
0.107
0.146
0.164
0.225
0.250
0.342
0.378
0.510
0.565
0.637
0.849
0.951
1.298
1.476
DIM A
INCH
NOM
0.023
0.023
0.020
0.020
0.020
0.018
0.018
0.016
0.016
0.014
0.014
0.013
0.013
0.013
0.013
0.011
0.011
0.010
Mechanical
Schematic
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ± 0.008
.XXX : ±0.004
mm: X,X : ± 0,20 X,XX : ±0,10
Product performance is limited to specified parameter. Data is subject to change without prior notice.
P11TJ3-XXX
0547JW
13200 Estrella
Ste. 205
2463 208th,
Ave., Bldg. B
Gardena, CA 90248
Torrance, CA 90501
Tel: (310) 325-1043
Phone: (310)533-1455
Fax: (310) 325-1044
Fax:
(310)533-1853
www.mpsind.com
http://www.mpsind.com
sales@mpsind.com
Email: sales@mpsind.com
