SMD POWER INDUCTOR
P10DR52 SERIES
• RoHS Compliant Product
• Inductance measured : < 100µH : 100KHz, 0.25V
RMS
• Inductance measured :
>
100µH : 1KHz, 0.25V
RMS
• Inductance Tolerance: J=±5%, K=±10%, L=15±%, M=±20%
Add suffix letter for tolerance after the part number
• I
RATED
: Max 10% inductance drop and
∆T=40°C
Temp Rise
• Operating Temperature: -40°C to +85°C
ELECTRICAL SPECIFICATION @ 25°C
PART NO
Mechanical
P10DR52-
2R2
2R7
5R6
6R8
8R2
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
271
L
±20%
(µH)
2.2
2.7
5.6
6.8
8.2
±10%
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
DCR
Max
(mW)
70
80
150
160
170
200
230
250
300
350
400
500
550
650
750
950
1200
1400
1750
2000
2600
3000
3700
RATED
I
DC
(A)
3.50
3.20
1.80
1.50
1.40
1.30
1.10
1.05
1.00
0.90
0.85
0.75
0.70
0.60
0.55
0.50
0.45
0.40
0.35
0.25
0.22
0.20
0.18
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ± 0.015 .XXX : ±0.004
mm: X,X : ± 0,38 X,XX : ±0,10
P10DR52-XX
0602JW
Schematic
Product performance is limited to specified parameter. Data is subject to change without prior notice.
2463 208th, Ste. 205
Torrance, CA 90501
Phone: (310)533-1455
Fax:
(310)533-1853
http://www.mpsind.com
Email: sales@mpsind.com
