SMD POWER INDUCTOR
P10DR53 SERIES
• RoHS Compliant Product
• Inductance measured : < 100µH : 100KHz, 0.25V
RMS
• Inductance measured :
>
100µH : 1KHz, 0.25V
RMS
• Inductance Tolerance: J=±5%, K=±10%, L=15±%, M=±20%
Add suffix letter for tolerance after the part number
• I
RATED
: Max 10% inductance drop and
∆T=40°C
Temp Rise
• Operating Temperature: -40°C to +85°C
ELECTRICAL SPECIFICATION @ 25°C
PART NO
Mechanical
P10DR53-
1R0
1R2
1R5
1R8M
2R2
2R7
3R3
3R9
4R7
5R6
6R8
8R2
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
271
331
391
471
561
681
821
102
L
±20%
(µH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
±10%
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
DCR
Max
(mW)
30
30
30
30
30
40
50
60
70
80
90
100
120
130
150
180
220
240
300
400
430
500
600
800
900
1000
1300
1500
2000
2500
3200
3500
4200
4500
6000
6500
8000
RATED
I
DC
(A)
4.5
4.2
4.1
3.7
3.5
3.2
2.8
2.6
2.5
2.4
2.2
2.0
1.8
1.8
1.7
1.6
1.5
1.4
1.1
1.00
0.90
0.85
0.80
0.65
0.60
0.58
0.43
0.41
0.38
0.35
0.28
0.26
0.20
0.19
0.18
0.15
0.13
Schematic
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ± 0.015 .XXX : ±0.004
mm: X,X : ± 0,38 X,XX : ±0,10
P10DR53-XX
0602JW
Product performance is limited to specified parameter. Data is subject to change without prior notice.
