SMD POWER INDUCTOR
P10DR73 SERIES
• RoHS Compliant Product
• Inductance measured : < 100µH : 100KHz, 0.25V
RMS
• Inductance measured :
>
100µH : 1KHz, 0.25V
RMS
• Inductance Tolerance: J=±5%, K=±10%, L=15±%, M=±20%
Add suffix letter for tolerance after the part number
• I
RATED
: Max 10% inductance drop and
∆T=40°C
Temp Rise
• Operating Temperature: -40°C to +85°C
ELECTRICAL SPECIFICATION @ 25°C
PART NO
Mechanical
P10DR73-
1R0
1R5
2R2
3R3
4R7
5R6
6R8
8R2
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
271
331
391
471
561
681
821
102
L
±20%
(µH)
1.0
1.5
2.2
3.3
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
DCR
Max
(mW)
10
13
18
25
35
40
50
60
80
90
100
110
130
150
170
220
250
280
330
410
480
540
750
1020
1200
1310
1500
1850
2200
2600
3200
3900
4500
RATED
I
DC
(A)
6.00
5.80
5.20
4.00
3.50
3.00
2.50
2.00
1.44
1.39
1.24
1.12
1.07
0.94
0.85
0.74
0.68
0.64
0.59
0.54
0.51
0.49
0.40
0.36
0.31
0.29
0.28
0.25
0.22
0.20
0.18
0.16
0.15
±10%
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Schematic
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ± 0.015 .XXX : ±0.004
mm: X,X : ± 0,38 X,XX : ±0,10
P10DR73-XX
0602JW
Product performance is limited to specified parameter. Data is subject to change without prior notice.
