MPU100 SERIES

100W Desk Top Switching Power Supplies For Medical Equipment.

Description:

The MPU100 series of AC/DC switching mode power supplies

provide 100 Watts of continuous output power . All supplies are

UL94V-1 min compliant, include IEC-320-C14 input for worldwide

applications.

They are ideally suited for use in hospital instrument

and many other applications.

All models meet FCC Part-18 class B

and CISPR-11 EN55011 class B emission Limits and are designed

to comply with UL/c-UL(UL 60601-1) ,TUV/T-mark (EN 60601-1)

and new CE requirements. All units are 100% burned in and tested.

Features:

Wide Input Voltage 90 to 264 VAC,47 to 63 Hz

IEC-320-C14 Input Inlet

Single to Triple Output

Output Voltage Available From 5VDC Thru 40VDC

Optional Output Connector (See appendix)

Input Surge Current, Over Voltage And Over Load protection

Splash proof

Power Factor Correction

Output Voltage Protection(Crowbar Design)

Class I Insulation

ON/OFF SWITCH

Two Years Warranty

Safety Approvals :

Electrical Characteristics:

Sym.

Vin

Fin

Iil

Iih

I rl

I rh

Parameter

Input Voltage

Input Frequency

Output Power Range

Output

Voltage Range

Output Current Range

Test Conditions

Operating Voltage

Min. Typ . Max. Unit

264

VAC

Vin=90

264VAC

100

See rating chart

1.25

0.5

Input Current (Low Line)

Input

Current ( High Line)

Low Line Inrush Current

Io=Full

load,

Vin=115

VAC

Io=Full load, Vin=230 VAC

Io=Full load, 25 C , Cool start,

Vin= 115VAC

Io=Full load, 25 C , Cool start,

Vin= 230VAC

Io=Full Load, Vin=230VAC

High Line Inrush Current

Eff

REG-i

REG-o

OVP

Efficiency

Line Regulation

Load Regulation

Over Voltage Protection

Over Current Protection

Transient

Response

Hold-Up Time

Start Up Time

Ripple & Noise (Peak to Peak)

Safety Ground Leakage C urrent

Temperature Coefficient

Io=Full Load

Vin=230VAC

112

110

0.5

132

150

%/ C

OCP

Ttr

Thold

Vrn

Ilk

Io=Full Load to Half Load, Vin=100VAC

Io=Full Load, Vin=110VAC

Io=Full Load, Vin=100VAC

Full Load, Vin=90VAC

Io = Fu ll Load, V i n = 240 V A C/60Hz

All output

0.3

1.5

-0.04

0.1

0.04

Environmental :

Sym.

Toper

Tstg

Parameter

Operating Temperature

Test Conditions

Min. Typ. Max.

-40

Unit

Storage Temperature

Relative Humidity

Derate linearly from 100% load at 50 C to 50% load at 70 C

Safety Specifications:

Sym.

Vps

Parameter

Test Conditions

Primary to secondary

Primary to ground

Test Voltage = 2100VDC

Vin=220VAC

Vin=110VAC

Min. Typ. Max.

5600

2800

Unit

VDC

CLASS

Dielectric Withstanding Voltage

for Primary to secondary

Dielectric

Vpg for Primary Withstanding Voltage

to Ground

Isolation Resistance

CISPR EMI requirements for CISPR-11

FCC EMI requirements for FCC PART-18
