APL5883
300mA Low Dropout Linear Regulator of Adjustable and Fixed 2.85V , 3.3V
Features
•
•
•
•
•
•
•
•
•
Low Dropout Voltage of 1.3V at 300mA
Output Voltage Accuracy
±
2.0%
Line Regulation - 1mV (typ.)
Load Regulation - 6mV (typ.)
Input Voltage Range up to 9V
Internal Current Limiting and Thermal Shutdown
Protections
Adjustable Output : 1.25V ~ 7.75V
Available Output Voltages - Ajdustable , 2.85V
and 3.3V
Various SOT-89 and TO-92 Packages Available
•
•
Portable Consumer Equipment
Low Voltage Systems
General Description
The APL5883 is a 3-pin low dropout linear regulator
with 2.0% accuracy of output voltage over line, load
and temperature variations. Dropout voltage at 300mA
output current is less than 1.2V. Both output current
limiting and thermal shutdown are built in to provide
maximal protection to the APL5883 against fault
conditions. The over current and thermal shutdown cir-
cuits become active when the current exceed 300mA,
or the junction temperature reach 150°C. Normal op-
eration is recovered when junction temperature drops
below 130°C.
Applications
•
•
•
•
Voltage Regulator for CD-ROM Drivers
Voltage Regulator for LAN Cards
Wireless Communication Systems
Portable Instrument
Pin Configuration
3
V
OUT
V
IN
A D J/G N D
2
1
2
3
1
A D J / G N D V
IN
V
OUT
SOT-89 (Top View)
TO-92 (Top View)
Ordering and Marking Information
AP L5883-
L e a d F re e C o d e
H a n d lin g C o d e
Tem p. R ange
P ackage C ode
V o lta g e C o d e
P ackage C ode
D : S O T -8 9
E : T O -9 2
Tem p. R ange
C : 0 to 7 0
°
C
H a n d lin g C o d e
TU : Tube
TR : Tape & R eel
V o lta g e C o d e
2 8 : 2 .8 5 V
3 3 : 3 .3 V
B la n k : A d ju s ta b le V e r s io n
L e a d F re e C o d e
L : L e a d F r e e D e v ic e
B la n k : O r ig in a l D e v ic e
APL
5883
XXXXX
APL
5883
XXXXX28
APL
5883
XXXXX33
A P L5883 D :
A P L5883
XXXXX
XXXXX
-
D a te C o d e
A P L5883 E :
XXXXX
-
D a te C o d e
A P L 5 8 8 3 -2 8 D :
A P L5883
XXXXX28
XXXXX
-
D a te C o d e
A P L 5 8 8 3 -2 8 E :
XXXXX
-
D a te C o d e
A P L 5 8 8 3 -3 3 D :
A P L5883
XXXXX33
XXXXX
-
D a te C o d e
A P L 5 8 8 3 -3 3 E :
XXXXX
-
D a te C o d e
ANPEC reserves the right to make changes to improve reliability or manufacturability without notice, and
drvise customers to obtain the latest version of relevant information to verify before placing orders.
Copyright
ANPEC Electronics Corp.
Rev. B.2 - Apr., 2003
1
www.anpec.com.tw
APL5883
Block Diagram
V
IN
Thermal
Shutdown
+
-
Current
Limit
V
OUT
V
REF
GND
Absolute Maximum Ratings
Symbol
V
IN
I
OUT
T
A
T
J
T
STG
P
D
θ
JA
Parameter
Input Voltage
Output Current
Operating Ambient Temperature Range
Operating Ambient Temperature Range
Storage Temperature Range
Power Dissipation Package
Thermal Resistance
SOT-89
TO- 92
Rating
9
300
0 to 70
-40 to +150
-65 to +150
Internal Limited
180
180
°C
/ W
Unit
V
mA
°C
°C
°C
Electrical Characteristics
Symbol
V
REF
V
IN
V
OUT
I
OUT
I
SC
I
Q
Parameter
Reference Voltage
(T
A
=25°C, unless otherwise noted)
APL5883
Min.
1.225
V
OUT
+1.3V
Test Condition
1.5V
≤(
V
I N
- V
O U T
)
≤
7. 75 V
10 mA
≤
I
O U T
≤3 0 0
m A,
T
J
=0 ~1 25
°
C
Typ.
1.250
Max.
1.275
9
1.02 V
OUT
Unit
V
V
V
mA
Input Voltage
Output Voltage
Output Current
Capability
Short Circuit Current
Quiescent Current
I
OUT
=10mA
V
OUT
=3.3V ,
∆V
OUT
=2%
V
OUT
<0.4V
V
IN
=5V , No Load
0.98 V
OUT
300
500
6
mA
10
mA
Copyright
ANPEC Electronics Corp.
Rev. B.2 - Apr., 2003
2
www.anpec.com.tw
APL5883
Typical Characteristics (Cont.)
Output Voltage vs. Input Voltage
Input Current vs. Input Voltage
3.35
8
7
3.33
3.31
3.29
Input Current (mA)
Output Voltage (V)
6
5
4
3
2
1
0
0
2
4
6
8
10
3.27
3.25
5
6
7
8
9
10
Input Voltage (V)
Input Voltage (V)
Short Current vs. Input Voltage
700
600
3.33
500
400
Short Current (mA)
300
200
100
0
0
2
4
6
8
10
Output Voltage (V)
3.31
3.29
3.27
3.35
Output Voltage vs. Output Current
3.25
0
100
200
300
Input Voltage (V)
Output Current (mA)
Copyright
ANPEC Electronics Corp.
Rev. B.2 - Apr., 2003
5
www.anpec.com.tw
